Large Diameter PE Pipe Hdpe Water Supply Pipe Size Dn500 1200mm Pipe

100
MOQ
0.5$(1~10per);0.43$(>1000per)
Price
Large Diameter PE Pipe Hdpe Water Supply Pipe Size Dn500 1200mm Pipe
Features Gallery Product Description Request A Quote
Features
Specifications
Brand Name: HAIYANG
Model Number: HM1-96
Specification: DN20-DN1100mm
Color: Black Or At Request
Usage: Water Supply
Raw Material: PE
Size: Customized Size
Working Pressure: 1.25mpa-2.5mpa
Sample: Provide Sample
Advantage: High Quality
Length: As Costomer Requirements
High Light:

ISO9001 Polypropylene Pipe Fittings

,

PPR cold water pipe Fittings

Basic Infomation
Place of Origin: China
Certification: ISO9001,14001,45001
Payment & Shipping Terms
Packaging Details: 50 or 100 per piece
Supply Ability: 5000 Metric Ton/Metric Tons per Year
Product Description

Large Diameter PE Pipe Hdpe Water Supply Pipe Size Dn500 1200mm Pipe

----------------------------------------



Basic Info.



HDPE water pipes are widely used in the field of water supply pipe manufacturing due to their high strength, corrosion resistance, and non-toxicity. It is an important component of water supply and drainage.



Outer Diameter
DN (mm)
SDR 9
PN20
SDR 11
PN16
SDR 13.6
PN12.5
SDR 17
PN10
SDR21
PN8
SDR26
PN6
Packing
Loaded into 40GP/Piece
6m or 12m per Piece
  Wall Thick Ness(mm) Wall Thick Ness(mm) Wall Thick Ness(mm) Wall Thick Ness(mm) Wall Thick Ness(mm) Wall Thick Ness(mm)
75 8.4 6.8 5.6 4.5     1085
90 10.1 8.2 6.7 5.4 4.3   754
110 12.3 10 8.1 6.6 5.3 4.2 504
125 14 11.4 9.2 7.4 6 4.8 378
140 15.7 12.7 10.3 8.3 6.7 5.4 304
160 17.9 14.6 11.8 9.5 7.7 6.2 224
180 20.1 16.4 13.3 10.7 8.6 6.9 182
200 22.4 18.2 14.7 11.9 9.6 7.7 143
225 25.2 20.5 16.6 13.4 10.8 8.6 110
250 27.9 22.7 18.4 14.8 11.9 9.6 90
280 31.3 25.4 20.6 16.6 13.4 10.7 72
315 35.2 28.6 23.2 18.7 15 12.1 56
355 39.7 32.2 26.1 21.1 16.9 13.6 42
400 44.7 36.3 29.4 23.7 19.1 15.3 30
450 50.3 40.9 33.1 26.7 21.5 17.2 25
500 55.8 45.4 36.8 29.7 23.9 19.1 20
560 62.5 50.8 41.2 33.2 26.7 21.4 16
630 70.3 57.2 46.3 37.4 30 24.1 12
710   64.5 52.2 42.1 33.9 27.2 9
800   72.7 58.8 47.4 38.1 30.6 6
900   81.8 66.2 53.3 42.9 34.4 6
1000   90.2 72.5 59.3 47.7 38.2 4
1200     88.2 67.9 57.2 45.9
1400     102.9 82.4 66.7 53.5
1500     110.2 88.2 71.4 57.6
1600     117.6 94.1 76.2 61.2





Advantage



1. Reliable connection: The polyethylene pipe parts are connected by electrothermal fusion, and the strength of the joint is higher than that of the pipe body.​

2. Good wear resistance: The comparative experiment on the wear resistance of HDPE pipes and steel pipes shows that the wear resistance of HDPE pipes is 4 times that of steel pipes. In the field of mud transportation, compared with steel pipes, HDPE pipes have better wear resistance, which means that HDPE pipes have longer service life and better economy.
3. Anti-aging and long service life: Poly-Zene pipes containing 2-2.5% of carbon black evenly distributed can be stored or used outdoors for 50 years without being damaged by ultraviolet radiation.



Details

Large Diameter PE Pipe Hdpe Water Supply Pipe Size Dn500 1200mm Pipe 0Large Diameter PE Pipe Hdpe Water Supply Pipe Size Dn500 1200mm Pipe 1Large Diameter PE Pipe Hdpe Water Supply Pipe Size Dn500 1200mm Pipe 2Large Diameter PE Pipe Hdpe Water Supply Pipe Size Dn500 1200mm Pipe 3









Application



Polyethylene PE water supply pipes are widely used in building water supply, building drainage, buried drainage pipes, building heating, gas transmission pipes, welding and telecommunications maintenance casings, industrial pipes, and agricultural pipes because of their unique advantages. Wait. Its key applications are urban water supply, urban gas supply, farmland irrigation and other industries. PE (polyethylene) raw materials are widely used in the water supply pipe manufacturing industry because of their high strength, corrosion resistance, and non-toxic properties; because it is not easy Rust, therefore, is an ideal pipe to replace ordinary iron water supply pipes.





Certificate



Large Diameter PE Pipe Hdpe Water Supply Pipe Size Dn500 1200mm Pipe 4

Large Diameter PE Pipe Hdpe Water Supply Pipe Size Dn500 1200mm Pipe 5

Large Diameter PE Pipe Hdpe Water Supply Pipe Size Dn500 1200mm Pipe 6



Company Profile



Located in Jiangsu, with convenient water and land transportation. It is a comprehensive enterprise integrating research, development, design, application, production and sales. The company has production lines for PE water supply pipes with larger diameters, prestressed corrugated pipes, corrugated pipe production lines, PVC pipe production lines and other equipment. Specializing in the production of PE water supply pipes, prestressed corrugated pipes, HDPE corrugated pipes, plastic blind trenches, permeable pipes, etc. The products are mainly used in municipal administration, highways, railways, water conservancy, power, environmental greening and infrastructure construction, and are used in municipalities and expressways. Many national key projects such as railways and railways have been well received by engineering experts and users.


Large Diameter PE Pipe Hdpe Water Supply Pipe Size Dn500 1200mm Pipe 7     Large Diameter PE Pipe Hdpe Water Supply Pipe Size Dn500 1200mm Pipe 8



Large Diameter PE Pipe Hdpe Water Supply Pipe Size Dn500 1200mm Pipe 9     Large Diameter PE Pipe Hdpe Water Supply Pipe Size Dn500 1200mm Pipe 10



FAQ



Q: How to buy products?
A: Send an email to us and we will get back to you within one day.



Q: Which payment method can your company use?
A: T/T, L/C or full trade insurance. You can choose the one that is convenient for you.



Q: How and when can I receive my goods after payment?
A: For small batch products, they will be delivered to you by international express (DHL, FedEx, TNT, etc.) or by air. It usually takes 3-5 days to receive the goods after delivery. For high-volume products, it is worthwhile to see the goods and deliver them. It takes several days to several weeks to reach the destination port, depending on the location of the port.
