Blue Color Drainage Large-Diameter Pipe 90 Deg Elbow PVC Drainage Water Pipe Fittings
----------------------------------------
Basic Info.
PVC drainage pipe is an alternative to traditional drainage pipes and has better physical and chemical properties. Its inner wall is smooth and has less frictional resistance than conventional drainage materials. Therefore, the installation slope of the horizontal pipe is small, which can increase the indoor net height of the building. At the same time, PVC drainage pipes are lighter in weight, one-fifth of cast iron pipes, easy to transport and operate; adhesive connection is used to facilitate installation and maintenance; the price is lower than conventional drainage pipes, which greatly reduces the project cost; strong corrosion resistance, in construction Sewage and rainwater pipe systems are widely used.
| DN.mm | Wall thickness(mm) | |||||
| 0.63 M pa | 0.8Mpa | l.OMpa | 1.25Mpa | 1.6Mpa | 2.0Mpa | |
| 20 | - | - | - | - | 2.0 | 2.0 |
| 25 | - | - | - | - | 2.0 | 2.0 |
| 32 | - | - | - | - | 2.0 | 2.0 |
| 40 | - | - | - | - | 2.0 | 2.0 |
| 50 | - | - | - | - | 2.0 | 2.4 |
| 50 | - | - | - | 2.0 | 2.4 | 3.0 |
| 63 | - | - | 2.0 | 2.5 | 3.0 | 3.8 |
| 75 | - | 2.0 | 2.3 | 2.9 | 3.6 | 4.5 |
| 90 | 2.0 | 2.2 | 2.8 | 3.5 | 4.3 | 6.5 |
| 110 | 2.2 | 2.7 | 3.4 | 4.2 | 5.3 | 6.6 |
| 125 | 2.5 | 3.1 | 3.9 | 4.8 | 6.0 | 7.4 |
| 140 | 2.8 | 3.5 | 4.3 | 5.4 | 6.7 | 8.3 |
| 160 | 3.2 | 4.0 | 4.9 | 6.2 | 7.7 | 9.5 |
| 180 | 3.6 | 4.4 | 5.5 | 6.9 | 8.6 | 10.7 |
| 200 | 3.9 | 4.9 | 6.2 | 7.7 | 9.6 | 11.9 |
| 225 | 4.4 | 5.5 | 6.9 | 8.6 | 10.8 | 13.4 |
| 250 | 4.9 | 6.2 | 7.7 | 9.6 | 11.9 | 14.8 |
| 280 | 5.5 | 6.9 | 8.6 | 10.7 | 13.4 | 16.6 |
| 315 | 6.2 | 7.7 | 9.7 | 12.1 | 15.0 | 18.7 |
| 355 | 7.0 | 8.7 | 10.9 | 13.6 | 16.9 | 21.1 |
| 400 | 7.9 | 9.8 | 12.3 | 15.3 | 19.1 | 23.7 |
| 450 | 8.8 | 11.0 | 13.8 | 17.2 | 21.5 | 26.7 |
| 500 | 8.9 | 12.3 | 15.3 | 19.1 | 23.9 | 29.7 |
| 560 | 11.0 | 13.7 | 17.2 | 21.4 | 26.7 | 33.2 |
| 630 | 12.3 | 15.4 | 19.3 | 24.1 | 30.0 | 37.4 |
Advantage
1. Light weight, convenient handling and handling: low density, convenient handling, handling, and construction.
2. Small fluid resistance: The inner wall of the pipe is smooth, its roughness coefficient is only 0.009, and the fluid resistance is small, which effectively improves the hydraulic conditions of the pipe network and reduces the operating cost of the system.
3. Excellent corrosion resistance: It has excellent acid resistance, alkali resistance and corrosion resistance, which is very suitable for the use of chemical industry.
4. High mechanical strength: The pipe has good pressure resistance, impact resistance and tensile strength.
5. Simple construction: The pipeline connection construction is quick and easy, and the construction cost is low.
6. Does not affect water quality: It is confirmed by the dissolution test that it does not affect water quality, and is suitable for large-scale promotion and application.
7. Low cost: low price, convenient transportation and construction, and long service life, so the overall cost is low.
Details
Application
1. Saw pipe and bevel:
The length of the saw pipe is determined layer by layer according to actual measurement and combined with the size of each connecting pipe. Saw pipe tools should use fine-tooth saws, cutters, pipe cutters and other tools. The fracture should be flat and there should be no deformation at the cross section. The part of the socket to be bonded can be filed into a 15o~30o groove with a medium plate file. The groove length is generally not less than 3mm, and the groove thickness should be 1/3~1/2 of the pipe wall thickness. After the bevel is completed, the debris should be removed.
2. Protection of socket interface:
After connecting the socket interface, wipe the extruded adhesive with cotton yarn or a dry cloth dipped in a little acetone and other cleaning agents. According to the performance of the adhesive and the weather conditions, let it sit until the interface is cured. The curing time should be appropriately extended during winter construction.
Certificate
Company Profile
High Mountain Pipe is a well-known PVC pipe manufacturer and wholesaler in Jiangsu. It produces multi-caliber HDPE pipes, pvc pipes, pvc hoses and accessories and supporting machines. The products are widely used. It is the first choice for watering and irrigation of agricultural and forestry breeding gardens. The pipeline is An essential transmission tool for industrial, agricultural, and construction engineering drainage cleaning. Complete specifications, can be customized according to customer needs, use quality to create a brand, and use service to win trust.
The company adheres to the people-oriented scientific development concept, correctly grasps product development trends, implements strategic target management, is committed to developing core manufacturing advantages, optimizing resource allocation and technological breakthroughs, introducing market-oriented and refined operating systems, achieving leapfrog development, and striving to build " "Rongchengxing" brand, implement a win-win strategy, and work hard for the development of the industry!
