Customized Size HDPE Double Wall Corrugated Pipe High Density
10 Meter/Meters
MOQ
0.5$/m(1~10m);0.43$/m(>1000m)
Price
Customized Size HDPE Double Wall Corrugated Pipe High Density
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: China
Brand Name: HWHP
Certification: ISO9001
Model Number: HM02010
High Light:

High Density Double Wall Corrugated Pipe

,

Double Wall Corrugated Pipe cracking resistance

,

HDPE Corrugated Pipe Reliable connection

Payment & Shipping Terms
Packaging Details: 6m or 12m per piece
Supply Ability: 5000 Metric Ton/Metric Tons per Year
Specifications
Brand Name: HAIYANG
Model Number: HM02010
Specification: DN20mm-1600mm
Color: Black
Usage: Water Draining
Raw Material: PE100
Size: Customized Size
MOQ: 100 Meters
Sample: Provide Samples
Advantage: High Performance
Product Description

Manufacturer Customized Size HDPE Double Wall Corrugated Pipe With High Quality And Low Price

----------------------------------------



Basic Info.



HDPE resin is high-density polyethylene with excellent chemical stability, aging resistance and environmental stress cracking resistance. The applicable temperature range is -40°C—40°C, with strong pressure-bearing capacity and good comprehensive mechanical properties.



Size   PN2.0MPa PN1.6MPa PN1.25MPa PN1.0MPa PN0.8MPa PN0.6MPa
    SDR 9 SDR 11 SDR 13.6 SDR 17 SDR 21 SDR 26
OD(inch) OD(mm) thickness thickness thickness thickness thickness thickness
1/2 20 2.3 2.3
3/4 25 3 2.3 2.3
1 32 3.6 3 2.4
1 1/4 40 4.5 3.7 3 2.4
1 1/2 50 5.6 4.6 3.7 3
2 63 7.1 5.8 4.7 3.8
2.5 75 8.4 6.8 5.6 4.5
3 90 10.1 8.2 6.7 5.4 4.3
4 110 12.3 10 8.1 6.6 5.3 4.2
5 125 14 11.4 9.2 7.4 6 4.8
5 140 15.7 12.7 10.3 8.3 6.7 5.4
6 160 17.9 14.6 11.8 9.5 7.7 6.2
7 180 20.1 16.4 13.3 10.7 8.6 6.9
8 200 22.4 18.2 14.7 11.9 9.6 7.7
8 225 25.2 20.5 16.6 13.4 10.8 8.6
10 250 27.9 22.7 18.4 14.8 11.9 9.6
11 280 31.3 25.4 20.6 16.6 13.4 10.7
12 315 35.2 28.6 23.2 18.7 15 12.1
14 355 39.7 32.2 26.1 21.1 16.9 13.6
16 400 44.7 36.3 29.4 23.7 19.1 15.3
18 450 50.3 40.9 33.1 26.7 21.5 17.2
20 500 55.8 45.4 36.8 29.7 23.9 19.1
22 560 62.5 50.8 41.2 33.2 26.7 21.4
24 630 70.3 57.2 46.3 37.4 30 24.1
28 710 79.3 64.5 52.2 42.1 33.9 27.2
32 800 89.3 72.6 58.8 47.4 38.1 30.6
36 900   81.8 66.2 53.3 42.9 34.4
40 1000   90.2 72.5 59.3 47.7 38.2
48 1200     88.2 67.9 57.2 45.9
55 1400     102.9 82.4 66.7 53.5
60 1500     110.2 88.2 71.4 57.6
65 1600     117.6 94.1 76.2 61.2



Customized Size HDPE Double Wall Corrugated Pipe High Density 0



Advantage



1. Reliable connection: The polyethylene piping systems are connected by electrothermal fusion, and the strength of the joint is higher than that of the pipe body.
2. Good impact resistance at low temperature: The low temperature embrittlement temperature of polyethylene is extremely low, and it can be used safely in the temperature range of -60-60 °C. During construction in winter, due to the good impact resistance of the material, the pipe will not be brittle.
3. Good resistance to stress cracking: HDPE has low notch sensitivity, high shear strength and excellent scratch resistance, and its resistance to environmental stress cracking is also very outstanding.
4. Good chemical corrosion resistance: HDPE pipes are resistant to corrosion by a variety of chemical media, and the chemicals present in the soil will not cause any degradation to the pipes. Polyethylene is an electrical insulator, so it does not rot, rust or electrochemically corrode; it also does not promote algal, bacterial or fungal growth.
5. Anti-aging and long service life: Polyethylene pipes containing 2-2.5% evenly distributed carbon black can be stored or used outdoors for 50 years without being damaged by ultraviolet radiation.



Details

Customized Size HDPE Double Wall Corrugated Pipe High Density 1

Customized Size HDPE Double Wall Corrugated Pipe High Density 2Customized Size HDPE Double Wall Corrugated Pipe High Density 3

Customized Size HDPE Double Wall Corrugated Pipe High Density 4






Application



1. Replacement of cement pipes, cast iron pipes and steel pipes: For the replacement of old pipes with cement pipes, cast iron pipes, etc. originally laid in the city, PE pipes can be directly inserted into the old pipes for replacement without extensive excavation, and the project cost is low , The construction time is short, especially suitable for the pipeline re-selection in the old city.
2. Landscaping pipe network: landscaping requires a large number of water pipelines, and PE pipes have low cost and are worthy of vigorous promotion.
3.Municipal trenchless engineering: At present, with the development of the city, trenchless technology is widely used in various constructions, and the pipe jacking (drag pipe, traction pipe) commonly used in trenchless factories is currently more popular. PE pipe, because of its toughness and price advantage, will have greater development in the trenchless field.
4. Sewage treatment: At present, many sewage treatment plants use PE pipes in addition to cement pipes and HDPE double-wall corrugated pipes. In construction such as turning and crossing, its convenience is even more prominent.
5. Electric power threading: Due to the superior resistance and insulation properties of PE pipes, as well as its own good compressive strength and tensile strength, it is often used in many power threading constructions.



Certificate



Customized Size HDPE Double Wall Corrugated Pipe High Density 5

Customized Size HDPE Double Wall Corrugated Pipe High Density 6

Customized Size HDPE Double Wall Corrugated Pipe High Density 7

Company Profile



High Mountain Pipe is a company specializing in the production of hdpe double-wall corrugated pipes, plastic corrugated pipes, hdpe drainage pipes, HDPE-enhanced double-wall hollow winding pipes, HDPE-enhanced double-wall socket flared hollow winding pipes, HDPE double-wall corrugated pipes, hollow bi-well pipes, HDPE An enterprise that winds structure wall B type pipe (carat pipe), HDPE wind structure wall C type pipe (carat pipe), and inner rib reinforced polyethylene spiral corrugated pipe. The company has 61 fully automated production equipment (large-caliber production lines) of advanced technology in the industry, and two imported testing equipment laboratories. It implements a strict quality control system to ensure the quality of products from raw materials to finished products. The product has been tested by the National Chemical Building Materials Testing Center, and the performance indicators of B and C pipes are in compliance with the GB/T19472.2-2017 standard. It has passed the China Environmental Protection Mark certification and won the 1S09001-2015 quality system certification.





Customized Size HDPE Double Wall Corrugated Pipe High Density 8     Customized Size HDPE Double Wall Corrugated Pipe High Density 9



Customized Size HDPE Double Wall Corrugated Pipe High Density 10     Customized Size HDPE Double Wall Corrugated Pipe High Density 11



FAQ



Q:Is the price on this page correct?
A: The listed price is only for reference, for latest price, pls contact us directly.



Q: Can you make special designs and logos on your products?
A: Yes, it is very easy.



Q: Can I customize the size I need?
A: Yes
