Hdpe Underground Water Supply Pipe 24inch High Quality Flexible Water Pipe

10 Meter/Meters
MOQ
0.5$/m(1~10m);0.43$/m(>1000m)
Price
Hdpe Underground Water Supply Pipe 24inch High Quality Flexible Water Pipe
Features Gallery Product Description Request A Quote
Features
Specifications
Brand Name: HAIYANG
Model Number: HM1-103
Specification: DN20-DN800mm
Color: Black,white,grey,green Or At Request
Usage: Water Supply
Raw Material: PE
Size: Customized Size
Working Pressure: 0.2mpa-2.5mpa
Sample: Provide Sample
Advantage: High Quality
Length: As Costomer Requirements
High Light:

1 Inch PPR Water Supply Pipes

,

Hot Welding PPR Water Supply Pipes

,

30mm Drainage Pipe

Basic Infomation
Place of Origin: China
Certification: ISO9001,14001,45001
Payment & Shipping Terms
Packaging Details: 6m or 12m per piece
Supply Ability: 5000 Metric Ton/Metric Tons per Year
Product Description

Hdpe Underground Water Supply Pipe 24inch High Quality Flexible Water Pipe

----------------------------------------



Basic Info.



HDPE is a very common material, that is, high-density polyethylene. HD means high-density, so the name implies. It is harder than ordinary PE plastic, milky white, has good chemical stability, and has a certain high and low temperature resistance. If the process is hygienic, it is a relatively "clean" material. HDPE water supply pipes and PE water supply pipes are both PE pipe fittings. HDPE is high-density polyethylene, and PE is polyethylene. That's the difference. But the physical properties are different.



Size   PN2.0MPa PN1.6MPa PN1.25MPa PN1.0MPa PN0.8MPa PN0.6MPa
    SDR 9 SDR 11 SDR 13.6 SDR 17 SDR 21 SDR 26
OD(inch) OD(mm) thickness thickness thickness thickness thickness thickness
1/2 20 2.3 2.3
3/4 25 3 2.3 2.3
1 32 3.6 3 2.4
1 1/4 40 4.5 3.7 3 2.4
1 1/2 50 5.6 4.6 3.7 3
2 63 7.1 5.8 4.7 3.8
2.5 75 8.4 6.8 5.6 4.5
3 90 10.1 8.2 6.7 5.4 4.3
4 110 12.3 10 8.1 6.6 5.3 4.2
5 125 14 11.4 9.2 7.4 6 4.8
5 140 15.7 12.7 10.3 8.3 6.7 5.4
6 160 17.9 14.6 11.8 9.5 7.7 6.2
7 180 20.1 16.4 13.3 10.7 8.6 6.9
8 200 22.4 18.2 14.7 11.9 9.6 7.7
8 225 25.2 20.5 16.6 13.4 10.8 8.6
10 250 27.9 22.7 18.4 14.8 11.9 9.6
11 280 31.3 25.4 20.6 16.6 13.4 10.7
12 315 35.2 28.6 23.2 18.7 15 12.1
14 355 39.7 32.2 26.1 21.1 16.9 13.6
16 400 44.7 36.3 29.4 23.7 19.1 15.3
18 450 50.3 40.9 33.1 26.7 21.5 17.2
20 500 55.8 45.4 36.8 29.7 23.9 19.1
22 560 62.5 50.8 41.2 33.2 26.7 21.4
24 630 70.3 57.2 46.3 37.4 30 24.1
28 710 79.3 64.5 52.2 42.1 33.9 27.2
32 800 89.3 72.6 58.8 47.4 38.1 30.6
36 900   81.8 66.2 53.3 42.9 34.4
40 1000   90.2 72.5 59.3 47.7 38.2
48 1200     88.2 67.9 57.2 45.9
55 1400     102.9 82.4 66.7 53.5
60 1500     110.2 88.2 71.4 57.6
65 1600     117.6 94.1 76.2 61.2





Advantage



1. Excellent resistance to rapid crack propagation (RCP).
2. Excellent flexibility and scratch resistance.
3. Good wear resistance, low wall friction coefficient, low flow resistance, and excellent conveying capacity.
4. A variety of non-excavation methods can be used, and the construction and installation are extremely convenient.
5. The system cost is low, and the maintenance cost is low, which can greatly reduce the project cost.



Details

     Hdpe Underground Water Supply Pipe 24inch High Quality Flexible Water Pipe 0Hdpe Underground Water Supply Pipe 24inch High Quality Flexible Water Pipe 1Hdpe Underground Water Supply Pipe 24inch High Quality Flexible Water Pipe 2Hdpe Underground Water Supply Pipe 24inch High Quality Flexible Water Pipe 3







Application



1. Municipal engineering water supply system
2. Building indoor water supply system
3. Outdoor buried water supply system and residential area
4. Buried water supply system in the plant
5. Old pipeline repair
6. Water treatment engineering piping system
7. Industrial water pipes in gardens, irrigation and other fields.



Certificate



Hdpe Underground Water Supply Pipe 24inch High Quality Flexible Water Pipe 4

Hdpe Underground Water Supply Pipe 24inch High Quality Flexible Water Pipe 5

Hdpe Underground Water Supply Pipe 24inch High Quality Flexible Water Pipe 6

Company Profile



Located in Jiangsu, with convenient water and land transportation. It is a comprehensive enterprise integrating research, development, design, application, production and sales. The company has production lines for PE water supply pipes with larger diameters, prestressed corrugated pipes, corrugated pipe production lines, PVC pipe production lines and other equipment. Specializing in the production of PE water supply pipes, prestressed corrugated pipes, HDPE corrugated pipes, plastic blind trenches, permeable pipes, etc. The products are mainly used in municipal administration, highways, railways, water conservancy, power, environmental greening and infrastructure construction, and are used in municipalities and expressways. Many national key projects such as railways and railways have been well received by engineering experts and users.


The company has always implemented the business philosophy of "integrity and pragmatism, diligence and self-reliance, high-quality service, innovative development", and is an ideal partner for users at home and abroad. Customer trust is the source of our Chuangda's rapid development and the driving force of Chuangda people's struggle. Chuangda Pipe Industry will use sincere service and continuous innovation of technology to return our customers and society with high-quality products. To support the development of the enterprise with high-tech and high-start products, to continuously improve the technical content of the products, and to increase the market share of the products; to survive by quality, to win users with service, to benefit from management, and to create high-quality projects with you is forever The pursuit!



Hdpe Underground Water Supply Pipe 24inch High Quality Flexible Water Pipe 7     Hdpe Underground Water Supply Pipe 24inch High Quality Flexible Water Pipe 8



Hdpe Underground Water Supply Pipe 24inch High Quality Flexible Water Pipe 9     Hdpe Underground Water Supply Pipe 24inch High Quality Flexible Water Pipe 10



FAQ



Q: What are your payment terms?
A: Accept the T/T and L/C terms.



Q: What is the delivery time?
A: We always have common products in stock and can be shipped within 30 days.
Large orders require 15 days to complete production.



Q: What is your warranty policy?
A: The product is guaranteed for two years from the date of shipment (or leaving the seller's factory depending on the terms).
It is also guaranteed that the product can be used for 50 years.
