Dn100 150 200 Ductile Cast Iron Fittings Plate Socket Type Elbow For Water Supply
10 Meter/Meters
MOQ
0.5$/m(1~10m);0.43$/m(>1000m)
Price
Dn100 150 200 Ductile Cast Iron Fittings Plate Socket Type Elbow For Water Supply
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: China
Brand Name: HWHP
Certification: ISO9001
Model Number: HM10002
High Light:

Dn150 Ductile Cast Iron Fittings

,

ISO 9001 Ductile Cast Iron Fittings

,

Dn100 Socket Type Elbow

Payment & Shipping Terms
Packaging Details: 6m or 12m per piece
Supply Ability: 5000 Metric Ton/Metric Tons per Year
Specifications
Brand Name: HAIYANG
Model Number: HM10002
Specification: DN80-2600mm
Color: Black,grey,or At Request
Usage: Water Supply
Raw Material: Carbon, Silicon, Manganese, Sulfur, Phosphorus, Magnesium,
Size: Customized Size
Standard: GB/T13295-2013 ISO2531/2003
Sample: Provide Sample
Advantage: High Quality
Length: As Costomer Requirements
Product Description

Ductile Cast Iron Fittings Dn100 150 200 Socket Plate Elbow Plate Socket Short Pipe For Water Supply

----------------------------------------



Basic Info.



Ductile iron pipe is made of magnesium or rare earth magnesium combined with gold spheroidizing agent added to the molten iron before pouring to spheroidize the graphite and reduce the stress concentration, so that the pipe has high strength, high elongation, impact resistance, corrosion resistance, and good sealing.



Diameter(mm) Outer diameter(mm) Wall thickness
(mm)
Weight/m
(kg)
Weight/root(kg) Root/km Weight/km(ton)
80 98 6 12.2 76.5 167 12.77
100 118 6.1 15.1 95 167 15.87
150 170 6.3 22.8 144 167 20.05
200 220 6.4 30.6 194 167 32.4
250 274 6.8 40.2 255 167 42.59
300 326 7.2 50.8 323 167 53.94
350 378 7.7 63.2 403 167 67.3
400 429 8.1 75.5 482 167 80.48
450 480 8.6 89.3 575 167 95.86
500 532 9 104.3 669 167 111.72
600 635 9.9 137.3 882 167 147.29
700 738 10.8 173.9 1123 167 187.54
800 842 11.7 215.2 1394 167 232.8
900 945 12.6 260.2 1691 167 282.4
1000 1048 13.5 309.3 2017 167 336.84
1200 1255 15.3 420.1 2758 167 460.69



Dn100 150 200 Ductile Cast Iron Fittings Plate Socket Type Elbow For Water Supply 0



Advantage



1. Since ductile iron pipe fittings use flexible joints, the construction operation is more convenient, which can improve construction efficiency, improve construction conditions, and reduce construction costs, and most of the interfaces are connected by rubber rings, which is easy to operate, can shorten the construction period and reduce the construction cost.
2. Ductile iron pipe fittings can withstand high water supply pressure, can withstand external loads and adapt to changes in geological conditions. The pipes have the advantages of high strength, good toughness, corrosion resistance, easy installation of flexible interfaces, strong earthquake resistance, low labor intensity, etc., which are applicable In areas with poor geology and crossing highways, no additional processing of steel pipes is required, and with strong corrosion resistance, it can be applied to coastal and saline-alkali zones. It is widely used in underground pipeline engineering. Large-scale pipeline installation projects can better reflect its advantages of convenient installation and low labor intensity.
3. The ductile iron pipe fittings have good sealing performance and are not easy to leak, which can reduce the leakage rate of the pipe network and reduce the daily maintenance cost of the pipe network.



Details



Dn100 150 200 Ductile Cast Iron Fittings Plate Socket Type Elbow For Water Supply 1     Dn100 150 200 Ductile Cast Iron Fittings Plate Socket Type Elbow For Water Supply 2



Dn100 150 200 Ductile Cast Iron Fittings Plate Socket Type Elbow For Water Supply 3     Dn100 150 200 Ductile Cast Iron Fittings Plate Socket Type Elbow For Water Supply 4





Application



It is suitable for the domestic drainage pipes of socket type and clamp type connection of gray cast iron pipes and supporting pipe fittings with internal and external pipe diameters of DN50mm~DN300mm and internal pressure not greater than 0.3MPa in new construction, expansion and reconstruction of civil and industrial buildings. , Rainwater pipes, non-corrosive industrial production wastewater pipes and rain down pipes.



Certificate



Dn100 150 200 Ductile Cast Iron Fittings Plate Socket Type Elbow For Water Supply 5

Dn100 150 200 Ductile Cast Iron Fittings Plate Socket Type Elbow For Water Supply 6

Dn100 150 200 Ductile Cast Iron Fittings Plate Socket Type Elbow For Water Supply 7

Company Profile



Our company's products are of high quality, and we always adhere to and implement the quality policy of "Quality is the foundation of a company's survival, and providing users with satisfactory products and services is our eternal pursuit". . Our company is a factory direct sale of ductile iron pipes, ductile iron pipe fittings, ductile iron manhole covers, Xinxing ductile pipes, ductile iron well grate; W type flexible cast iron pipe, W type cast iron drainage pipe and pipe fittings; A type flexible cast iron pipe, A type cast iron drainage Pipes and fittings, B-type flexible cast iron pipes, B-type cast iron drainage pipes and pipe fittings and other products. Our company is a group company integrating production and sales. The annual production capacity of ductile iron pipes and flexible drainage pipes is 300,000 tons; the annual sales volume of ductile iron pipes is 120,000 tons and the annual sales volume of flexible drainage pipes is 180,000 tons.



Dn100 150 200 Ductile Cast Iron Fittings Plate Socket Type Elbow For Water Supply 8     Dn100 150 200 Ductile Cast Iron Fittings Plate Socket Type Elbow For Water Supply 9



Dn100 150 200 Ductile Cast Iron Fittings Plate Socket Type Elbow For Water Supply 10     Dn100 150 200 Ductile Cast Iron Fittings Plate Socket Type Elbow For Water Supply 11



FAQ



Q: What certificates do you have for this product?
A: ISO, CE, SGS, etc.



Q: How to buy products?
A: Send an email to us and we will get back to you within one day.



Q: Is the price on this page correct?
A: The listed prices are for reference only, please contact us directly for the latest prices.
