Hdpe Pipe 800mm Hdpe Water Pipe Price Water Supply 4 Inch Hdpe Pipe

10 Meter/Meters
MOQ
0.5$/m(1~10m);0.43$/m(>1000m)
Price
Hdpe Pipe 800mm Hdpe Water Pipe Price Water Supply 4 Inch Hdpe Pipe
Features Gallery Product Description Request A Quote
Features
Specifications
Brand Name: BAILUN
Model Number: HM1-101
Specification: DN20-DN1100mm
Color: White Or At Request
Usage: Water Supply
Raw Material: PPR
Size: Customized Size
Working Pressure: 1.25mpa-2.5mpa
Sample: Provide Sample
Advantage: High Quality
Length: As Costomer Requirements
High Light:

PPR Water Supply Pipes DN25mm

,

ISO9001 PPR Hot And Cold Water Pipe

,

32mm PPR Hot Water Pipe Insulation

Basic Infomation
Place of Origin: China
Certification: ISO9001,14001,45001
Payment & Shipping Terms
Packaging Details: 100m or 40m per piece
Supply Ability: 5000 Metric Ton/Metric Tons per Year
Product Description

Hdpe Pipe 800mm Hdpe Water Pipe Price Water Supply 4 Inch Hdpe Pipe

----------------------------------------



Basic Info.



HDPE is a very common material, that is, high-density polyethylene. HD means high-density, so the name implies. It is harder than ordinary PE plastic, milky white, has good chemical stability, and has a certain high and low temperature resistance. If the process is hygienic, it is a relatively "clean" material. HDPE water supply pipes and PE water supply pipes are both PE pipe fittings. HDPE is high-density polyethylene, and PE is polyethylene. That's the difference. But the physical properties are different.



Size   PN2.0MPa PN1.6MPa PN1.25MPa PN1.0MPa PN0.8MPa PN0.6MPa
    SDR 9 SDR 11 SDR 13.6 SDR 17 SDR 21 SDR 26
OD(inch) OD(mm) thickness thickness thickness thickness thickness thickness
1/2 20 2.3 2.3
3/4 25 3 2.3 2.3
1 32 3.6 3 2.4
1 1/4 40 4.5 3.7 3 2.4
1 1/2 50 5.6 4.6 3.7 3
2 63 7.1 5.8 4.7 3.8
2.5 75 8.4 6.8 5.6 4.5
3 90 10.1 8.2 6.7 5.4 4.3
4 110 12.3 10 8.1 6.6 5.3 4.2
5 125 14 11.4 9.2 7.4 6 4.8
5 140 15.7 12.7 10.3 8.3 6.7 5.4
6 160 17.9 14.6 11.8 9.5 7.7 6.2
7 180 20.1 16.4 13.3 10.7 8.6 6.9
8 200 22.4 18.2 14.7 11.9 9.6 7.7
8 225 25.2 20.5 16.6 13.4 10.8 8.6
10 250 27.9 22.7 18.4 14.8 11.9 9.6
11 280 31.3 25.4 20.6 16.6 13.4 10.7
12 315 35.2 28.6 23.2 18.7 15 12.1
14 355 39.7 32.2 26.1 21.1 16.9 13.6
16 400 44.7 36.3 29.4 23.7 19.1 15.3
18 450 50.3 40.9 33.1 26.7 21.5 17.2
20 500 55.8 45.4 36.8 29.7 23.9 19.1
22 560 62.5 50.8 41.2 33.2 26.7 21.4
24 630 70.3 57.2 46.3 37.4 30 24.1
28 710 79.3 64.5 52.2 42.1 33.9 27.2
32 800 89.3 72.6 58.8 47.4 38.1 30.6
36 900   81.8 66.2 53.3 42.9 34.4
40 1000   90.2 72.5 59.3 47.7 38.2
48 1200     88.2 67.9 57.2 45.9
55 1400     102.9 82.4 66.7 53.5
60 1500     110.2 88.2 71.4 57.6
65 1600     117.6 94.1 76.2 61.2





Advantage



1. A variety of non-excavation methods can be used, and the construction and installation are extremely convenient.
2. The system cost is low, and the maintenance cost is low, which can greatly reduce the project cost.

3. No leakage: PE pipe adopts electrofusion connection, and its interface strength is higher than the pipe itself.
4. High toughness: The elongation at break of PE pipe is generally above 500%.For the uneven settlement of the base layer, its adaptability is very strong and the seismic performance is good.
5. Excellent resistance to rapid crack propagation (RCP).
6. Excellent flexibility and scratch resistance.
7. Good wear resistance, low wall friction coefficient, low flow resistance, and excellent conveying capacity.



Details



Hdpe Pipe 800mm Hdpe Water Pipe Price Water Supply 4 Inch Hdpe Pipe 0Hdpe Pipe 800mm Hdpe Water Pipe Price Water Supply 4 Inch Hdpe Pipe 1Hdpe Pipe 800mm Hdpe Water Pipe Price Water Supply 4 Inch Hdpe Pipe 2Hdpe Pipe 800mm Hdpe Water Pipe Price Water Supply 4 Inch Hdpe Pipe 3







Application



1. Industrial water pipes in gardens, irrigation and other fields.​

2. Outdoor buried water supply system and residential area
3. Buried water supply system in the plant
4. Old pipeline repair
5. Water treatment engineering piping system





Certificate



Hdpe Pipe 800mm Hdpe Water Pipe Price Water Supply 4 Inch Hdpe Pipe 4

Hdpe Pipe 800mm Hdpe Water Pipe Price Water Supply 4 Inch Hdpe Pipe 5

Hdpe Pipe 800mm Hdpe Water Pipe Price Water Supply 4 Inch Hdpe Pipe 6

Company Profile



Located in Jiangsu, with convenient water and land transportation. It is a comprehensive enterprise integrating research, development, design, application, production and sales. The company has production lines for PE water supply pipes with larger diameters, prestressed corrugated pipes, corrugated pipe production lines, PVC pipe production lines and other equipment. Specializing in the production of PE water supply pipes, prestressed corrugated pipes, HDPE corrugated pipes, plastic blind trenches, permeable pipes, etc. The products are mainly used in municipal administration, highways, railways, water conservancy, power, environmental greening and infrastructure construction, and are used in municipalities and expressways. Many national key projects such as railways and railways have been well received by engineering experts and users.



The company analyzes the lifestyle and aesthetic trends of modern people, integrates the concept of excellent pipeline home culture, and relies on the industry-leading integrated system of R&D, design, production, installation, and service to develop a one-stop personalized customized pipeline system solution. Provide optimized, cost-effective health products for thousands of families.



Hdpe Pipe 800mm Hdpe Water Pipe Price Water Supply 4 Inch Hdpe Pipe 7     Hdpe Pipe 800mm Hdpe Water Pipe Price Water Supply 4 Inch Hdpe Pipe 8



Hdpe Pipe 800mm Hdpe Water Pipe Price Water Supply 4 Inch Hdpe Pipe 9     Hdpe Pipe 800mm Hdpe Water Pipe Price Water Supply 4 Inch Hdpe Pipe 10



FAQ



Q: What is your minimum order quantity?
A: Accessories: one box or one bag.
Pipeline: 200~5000 meters/size, depending on different sizes.



Q: What is the delivery time?
A: We always have common products in stock and can be shipped within 30 days.
Large orders require 15 days to complete production.



Q: How to get free samples?
A: Send your address, telephone number, zip code and express account number to our mailbox, and tell us which model of samples you need. Our sales team will contact you within 24 hours.
