Black Hdpe Plastic Water Pipe Water Supply High-Density Polyethylene Sewage Pipe

10 Meter/Meters
MOQ
0.5$/m(1~10m);0.43$/m(>1000m)
Price
Black Hdpe Plastic Water Pipe Water Supply High-Density Polyethylene Sewage Pipe
Features Gallery Product Description Request A Quote
Features
Specifications
Brand Name: BAILUN
Model Number: HM1-105
Specification: DN20-DN1100mm
Color: White Or At Request
Usage: Water Supply
Raw Material: PE
Size: Customized Size
Working Pressure: 1.25mpa-2.5mpa
Sample: Provide Sample
Advantage: High Quality
Length: As Costomer Requirements
High Light:

Insulation Ppr Pipe For Chilled Water System

,

Water Supply DN40mm PPR Pipe

,

Customized Size PPR Plumbing Pipe

Basic Infomation
Place of Origin: China
Brand Name: HWHP
Certification: ISO9001,14001,45001
Model Number: HM1-105
Payment & Shipping Terms
Packaging Details: 100m or 40m per piece
Supply Ability: 5000 Metric Ton/Metric Tons per Year
Product Description

Black Hdpe Plastic Water Pipe Water Supply High-Density Polyethylene Sewage Pipe

----------------------------------------



Basic Info.



HDPE pipe is a highly crystalline, non-polar thermoplastic resin. Generally, the application range of PE pipes for water supply pipelines is below 40°C, and cannot be used for hot water delivery pipelines. The appearance of the original HDPE is milky white, and it is translucent to a certain extent in the thin section. PE pipe material has excellent resistance to most household and industrial chemicals. Certain types of chemicals are chemically aggressive, such as corrosive oxidants (concentrated nitric acid), aromatic hydrocarbons (xylene), and halogenated hydrocarbons (carbon tetrachloride).



Size   PN2.0MPa PN1.6MPa PN1.25MPa PN1.0MPa PN0.8MPa PN0.6MPa
    SDR 9 SDR 11 SDR 13.6 SDR 17 SDR 21 SDR 26
OD(inch) OD(mm) thickness thickness thickness thickness thickness thickness
1/2 20 2.3 2.3
3/4 25 3 2.3 2.3
1 32 3.6 3 2.4
1 1/4 40 4.5 3.7 3 2.4
1 1/2 50 5.6 4.6 3.7 3
2 63 7.1 5.8 4.7 3.8
2.5 75 8.4 6.8 5.6 4.5
3 90 10.1 8.2 6.7 5.4 4.3
4 110 12.3 10 8.1 6.6 5.3 4.2
5 125 14 11.4 9.2 7.4 6 4.8
5 140 15.7 12.7 10.3 8.3 6.7 5.4
6 160 17.9 14.6 11.8 9.5 7.7 6.2
7 180 20.1 16.4 13.3 10.7 8.6 6.9
8 200 22.4 18.2 14.7 11.9 9.6 7.7
8 225 25.2 20.5 16.6 13.4 10.8 8.6
10 250 27.9 22.7 18.4 14.8 11.9 9.6
11 280 31.3 25.4 20.6 16.6 13.4 10.7
12 315 35.2 28.6 23.2 18.7 15 12.1
14 355 39.7 32.2 26.1 21.1 16.9 13.6
16 400 44.7 36.3 29.4 23.7 19.1 15.3
18 450 50.3 40.9 33.1 26.7 21.5 17.2
20 500 55.8 45.4 36.8 29.7 23.9 19.1
22 560 62.5 50.8 41.2 33.2 26.7 21.4
24 630 70.3 57.2 46.3 37.4 30 24.1
28 710 79.3 64.5 52.2 42.1 33.9 27.2
32 800 89.3 72.6 58.8 47.4 38.1 30.6
36 900   81.8 66.2 53.3 42.9 34.4
40 1000   90.2 72.5 59.3 47.7 38.2
48 1200     88.2 67.9 57.2 45.9
55 1400     102.9 82.4 66.7 53.5
60 1500     110.2 88.2 71.4 57.6
65 1600     117.6 94.1 76.2 61.2





Advantage



1. Thermal conductivity: pipes used for floor heating need to have good thermal conductivity. PE-RT has better thermal conductivity, and its thermal conductivity is twice that of PP-R and PP-B pipes. It is very suitable for floor heating.
2. High temperature resistance: The high temperature resistance of PE-RT can reach 90°C, while that of PEX can only reach 65°C.
3. Low temperature thermal shock resistance: PE-RT has better low temperature shock resistance. During winter construction, the pipes are not susceptible to impact and rupture, which increases the flexibility of construction arrangements.





Details



Black Hdpe Plastic Water Pipe Water Supply High-Density Polyethylene Sewage Pipe 0Black Hdpe Plastic Water Pipe Water Supply High-Density Polyethylene Sewage Pipe 1Black Hdpe Plastic Water Pipe Water Supply High-Density Polyethylene Sewage Pipe 2Black Hdpe Plastic Water Pipe Water Supply High-Density Polyethylene Sewage Pipe 3







Application



Urban water pipe network system
Replaceable cement, cast iron and steel pipes
Industrial raw material pipeline
Landscaping water supply network
Pipes for sewage discharge
agricultural irrigation pipes
marine pipeline



Certificate



Black Hdpe Plastic Water Pipe Water Supply High-Density Polyethylene Sewage Pipe 4

Black Hdpe Plastic Water Pipe Water Supply High-Density Polyethylene Sewage Pipe 5

Black Hdpe Plastic Water Pipe Water Supply High-Density Polyethylene Sewage Pipe 6

Company Profile



Located in Jiangsu, with convenient water and land transportation. It is a comprehensive enterprise integrating research, development, design, application, production and sales. The company has production lines for PE water supply pipes with larger diameters, prestressed corrugated pipes, corrugated pipe production lines, PVC pipe production lines and other equipment. Specializing in the production of PE water supply pipes, prestressed corrugated pipes, HDPE corrugated pipes, plastic blind trenches, permeable pipes, etc. The products are mainly used in municipal administration, highways, railways, water conservancy, power, environmental greening and infrastructure construction, and are used in municipalities and expressways. Many national key projects such as railways and railways have been well received by engineering experts and users.



The company analyzes the lifestyle and aesthetic trends of modern people, integrates the concept of excellent pipeline home culture, and relies on the industry-leading integrated system of R&D, design, production, installation, and service to develop a one-stop personalized customized pipeline system solution. Provide optimized, cost-effective health products for thousands of families.



Black Hdpe Plastic Water Pipe Water Supply High-Density Polyethylene Sewage Pipe 7     Black Hdpe Plastic Water Pipe Water Supply High-Density Polyethylene Sewage Pipe 8



Black Hdpe Plastic Water Pipe Water Supply High-Density Polyethylene Sewage Pipe 9     Black Hdpe Plastic Water Pipe Water Supply High-Density Polyethylene Sewage Pipe 10



FAQ



Q: Why choose us?
A: We are a professional manufacturer with competitive price, excellent quality and fast delivery time.



Q: How to buy products?
A: Send an email to us and we will get back to you within one day.



Q: Can you make special designs and logos on your products?
A: Yes, it is very easy.
