HDPE Water Supply Pipe System Pe Sewage Irrigation Hdpe Pipes & Irrigation Pipes

10 Meter/Meters
MOQ
0.5$/m(1~10m);0.43$/m(>1000m)
Price
HDPE Water Supply Pipe System Pe Sewage Irrigation Hdpe Pipes & Irrigation Pipes
Features Gallery Product Description Request A Quote
Features
Specifications
Brand Name: BAILUN
Model Number: HM1-104a
Specification: DN20-DN1100mm
Color: White Or At Request
Usage: Water Supply
Raw Material: PPR
Size: Customized Size
Working Pressure: 1.25mpa-2.5mpa
Sample: Provide Sample
Advantage: High Quality
Length: As Costomer Requirements
High Light:

Plastic PPR Pipe DN50mm

,

OEM Hot Water Supply PPR Pipe

,

1.6mpa PPR Pipe For Hot Water Supply

Basic Infomation
Place of Origin: China
Certification: ISO9001,14001,45001
Payment & Shipping Terms
Packaging Details: 100m or 40m per piece
Supply Ability: 5000 Metric Ton/Metric Tons per Year
Product Description

HDPE Water Supply Pipe System Pe Sewage Irrigation Hdpe Pipes & Irrigation Pipes

----------------------------------------



Basic Info.



There are many classification methods of HDPE pipes, which can be divided into water supply pipes, gas pipes, aluminum-plastic composite pipes, buried drainage pipes, agricultural irrigation pipes and electrical casings according to the application field; according to the pressure conditions, they can be divided into pressure pipes and non-pressure pipes. , water supply pipes and gas pipes belong to the category of pressure pipes.



Size   PN2.0MPa PN1.6MPa PN1.25MPa PN1.0MPa PN0.8MPa PN0.6MPa
    SDR 9 SDR 11 SDR 13.6 SDR 17 SDR 21 SDR 26
OD(inch) OD(mm) thickness thickness thickness thickness thickness thickness
1/2 20 2.3 2.3
3/4 25 3 2.3 2.3
1 32 3.6 3 2.4
1 1/4 40 4.5 3.7 3 2.4
1 1/2 50 5.6 4.6 3.7 3
2 63 7.1 5.8 4.7 3.8
2.5 75 8.4 6.8 5.6 4.5
3 90 10.1 8.2 6.7 5.4 4.3
4 110 12.3 10 8.1 6.6 5.3 4.2
5 125 14 11.4 9.2 7.4 6 4.8
5 140 15.7 12.7 10.3 8.3 6.7 5.4
6 160 17.9 14.6 11.8 9.5 7.7 6.2
7 180 20.1 16.4 13.3 10.7 8.6 6.9
8 200 22.4 18.2 14.7 11.9 9.6 7.7
8 225 25.2 20.5 16.6 13.4 10.8 8.6
10 250 27.9 22.7 18.4 14.8 11.9 9.6
11 280 31.3 25.4 20.6 16.6 13.4 10.7
12 315 35.2 28.6 23.2 18.7 15 12.1
14 355 39.7 32.2 26.1 21.1 16.9 13.6
16 400 44.7 36.3 29.4 23.7 19.1 15.3
18 450 50.3 40.9 33.1 26.7 21.5 17.2
20 500 55.8 45.4 36.8 29.7 23.9 19.1
22 560 62.5 50.8 41.2 33.2 26.7 21.4
24 630 70.3 57.2 46.3 37.4 30 24.1
28 710 79.3 64.5 52.2 42.1 33.9 27.2
32 800 89.3 72.6 58.8 47.4 38.1 30.6
36 900   81.8 66.2 53.3 42.9 34.4
40 1000   90.2 72.5 59.3 47.7 38.2
48 1200     88.2 67.9 57.2 45.9
55 1400     102.9 82.4 66.7 53.5
60 1500     110.2 88.2 71.4 57.6
65 1600     117.6 94.1 76.2 61.2





Advantage



1. Corrosion resistance: No anti-corrosion layer is required for pipelines buried underground, and the service life is as long as 50 years.
2. No leakage: hot-melt connection is adopted, and the interface strength is higher than that of the pipe body.
3. High toughness: The elongation at break of PE pipes generally exceeds 500%, and it has a very strong adaptability to ground subsidence. It is a pipe with excellent seismic performance.
4. Flexibility: The pipe can be supplied in coils, and the amount of trench excavation is small, which is especially suitable for trenchless construction technology.
5. Light weight, low construction labor intensity, convenient and fast installation.
6. The water flow resistance is small, and the pipeline has a smooth inner surface, which reduces the pressure loss of the pipeline and the energy consumption of water delivery.



Details



HDPE Water Supply Pipe System Pe Sewage Irrigation Hdpe Pipes & Irrigation Pipes 0HDPE Water Supply Pipe System Pe Sewage Irrigation Hdpe Pipes & Irrigation Pipes 1HDPE Water Supply Pipe System Pe Sewage Irrigation Hdpe Pipes & Irrigation Pipes 2HDPE Water Supply Pipe System Pe Sewage Irrigation Hdpe Pipes & Irrigation Pipes 3







Application



The materials used in HDPE pipes are mainly polyvinyl chloride (PVC), polyethylene (PE) and polypropylene (PP). Compared with other plastic pipes (such as PVC), high-density polyethylene (HDPE) pipes have the characteristics of low density, good toughness, corrosion resistance, good insulation performance, easy construction and installation, and are widely used in municipal and building water supply and drainage, gas , heating and heating, wire and cable threading, agricultural water-saving irrigation and other fields.



Certificate



HDPE Water Supply Pipe System Pe Sewage Irrigation Hdpe Pipes & Irrigation Pipes 4

HDPE Water Supply Pipe System Pe Sewage Irrigation Hdpe Pipes & Irrigation Pipes 5

HDPE Water Supply Pipe System Pe Sewage Irrigation Hdpe Pipes & Irrigation Pipes 6

Company Profile



Located in Jiangsu, with convenient water and land transportation. It is a comprehensive enterprise integrating research, development, design, application, production and sales. The company has production lines for PE water supply pipes with larger diameters, prestressed corrugated pipes, corrugated pipe production lines, PVC pipe production lines and other equipment. Specializing in the production of PE water supply pipes, prestressed corrugated pipes, HDPE corrugated pipes, plastic blind trenches, permeable pipes, etc. The products are mainly used in municipal administration, highways, railways, water conservancy, power, environmental greening and infrastructure construction, and are used in municipalities and expressways. Many national key projects such as railways and railways have been well received by engineering experts and users.



The company analyzes the lifestyle and aesthetic trends of modern people, integrates the concept of excellent pipeline home culture, and relies on the industry-leading integrated system of R&D, design, production, installation, and service to develop a one-stop personalized customized pipeline system solution. Provide optimized, cost-effective health products for thousands of families.



HDPE Water Supply Pipe System Pe Sewage Irrigation Hdpe Pipes & Irrigation Pipes 7     HDPE Water Supply Pipe System Pe Sewage Irrigation Hdpe Pipes & Irrigation Pipes 8



HDPE Water Supply Pipe System Pe Sewage Irrigation Hdpe Pipes & Irrigation Pipes 9     HDPE Water Supply Pipe System Pe Sewage Irrigation Hdpe Pipes & Irrigation Pipes 10



FAQ



Q: What is the delivery time?
A: We always have common products in stock and can be shipped within 30 days.
Large orders require 15 days to complete production.



Q: How to get free samples?
A: Send your address, telephone number, zip code and express account number to our mailbox, and tell us which model of samples you need. Our sales team will contact you within 24 hours.



Q: What is your minimum order quantity?
A: Accessories: one box or one bag.
Pipeline: 200~5000 meters/size, depending on different sizes.
