White Grey PVC Drainage Pipe 3 Inch For Hydroponic
10 Meter/Meters
MOQ
0.5$/m(1~10m);0.43$/m(>1000m)
Price
White Grey PVC Drainage Pipe 3 Inch For Hydroponic
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: China
Brand Name: HWHP
Certification: ISO9001
Model Number: HM06006-1
High Light:

PVC Drainage Pipe Fittings For Hydroponic

,

White Grey PVC Drainage Pipe Fittings

,

3 Inch PVC Drainage Pipe Fittings

Payment & Shipping Terms
Packaging Details: 6m or 12m per piece
Supply Ability: 5000 Metric Ton/Metric Tons per Year
Specifications
Brand Name: HAIYANG
Model Number: HM06006-1
Specification: DN20-DN800mm
Usage: Water Supply
Raw Material: PVC
Size: Customized Size
Color: Black,white,grey,green Or At Request
Working Pressure: 0.2mpa-2.5mpa
Sample: Provide Sample
Advantage: High Quality
Length: As Costomer Requirements
Product Description

White Grey PVC Drainage Pipe 3 Inch PVC Pipe Fittings For Hydroponic

----------------------------------------



Basic Info.



PVC is the abbreviation of (Polyvinylchlorid), the main component is polyvinyl chloride, and other components are added to enhance its heat resistance, toughness, and ductility. The top layer of this surface film is lacquer, the main component in the middle is polyvinyl chloride, and the bottom layer is back-coated adhesive.
It is a kind of synthetic material that is well-loved, popular and widely used in the world today. Its global usage ranks second among various synthetic materials. According to statistics, in 1995 alone, the production of PVC in Europe was about 5 million tons, while its consumption was 5.3 million tons. In Germany, the production and consumption of PVC is an average of 1.4 million tons.



DN.mm Wall thickness(mm)
0.63 M pa 0.8Mpa l.OMpa 1.25Mpa 1.6Mpa 2.0Mpa
20 - - - - 2.0 2.0
25 - - - - 2.0 2.0
32 - - - - 2.0 2.0
40 - - - - 2.0 2.0
50 - - - - 2.0 2.4
50 - - - 2.0 2.4 3.0
63 - - 2.0 2.5 3.0 3.8
75 - 2.0 2.3 2.9 3.6 4.5
90 2.0 2.2 2.8 3.5 4.3 6.5
110 2.2 2.7 3.4 4.2 5.3 6.6
125 2.5 3.1 3.9 4.8 6.0 7.4
140 2.8 3.5 4.3 5.4 6.7 8.3
160 3.2 4.0 4.9 6.2 7.7 9.5
180 3.6 4.4 5.5 6.9 8.6 10.7
200 3.9 4.9 6.2 7.7 9.6 11.9
225 4.4 5.5 6.9 8.6 10.8 13.4
250 4.9 6.2 7.7 9.6 11.9 14.8
280 5.5 6.9 8.6 10.7 13.4 16.6
315 6.2 7.7 9.7 12.1 15.0 18.7
355 7.0 8.7 10.9 13.6 16.9 21.1
400 7.9 9.8 12.3 15.3 19.1 23.7
450 8.8 11.0 13.8 17.2 21.5 26.7
500 8.9 12.3 15.3 19.1 23.9 29.7
560 11.0 13.7 17.2 21.4 26.7 33.2
630 12.3 15.4 19.3 24.1 30.0 37.4



White Grey PVC Drainage Pipe 3 Inch For Hydroponic 0



Advantage


1. Small fluid resistance: The inner wall of the pipe is smooth, its roughness coefficient is only 0.009, and the fluid resistance is small, which effectively improves the hydraulic conditions of the pipe network and reduces the operating cost of the system.
2. Excellent corrosion resistance: It has excellent acid resistance, alkali resistance and corrosion resistance, which is very suitable for the use of chemical industry.
3. High mechanical strength: The pipe has good pressure resistance, impact resistance and tensile strength.
4. Simple construction: The pipeline connection construction is quick and easy, and the construction cost is low.
5. Does not affect water quality: It is confirmed by the dissolution test that it does not affect water quality, and is suitable for large-scale promotion and application.
6. Low cost: low price, convenient transportation and construction, and long service life, so the overall cost is low.



Details

White Grey PVC Drainage Pipe 3 Inch For Hydroponic 1White Grey PVC Drainage Pipe 3 Inch For Hydroponic 2White Grey PVC Drainage Pipe 3 Inch For Hydroponic 3White Grey PVC Drainage Pipe 3 Inch For Hydroponic 4


Application



PVC pipe has been regarded as the preferred pipe material by the construction industry. It is widely used in various fields and industries. From its own characteristics, it can be fully reflected in the waterway system. Then, what should we pay attention to during the installation process?
1. In order to ensure the safety and cleanliness of the PVC pipe, the pipe should be placed on the top with a bracket, which can ensure that the pipe is not placed anywhere and is not trampled by people, the pipe can also be used cleanly, and it can also prevent sludge residue in the pipe;
2. Before installation, the layout of the construction pipeline should be checked clearly, not only neat, but also strong in structure and smooth;
3. When installing, handle the pipe lightly to avoid damage during handling, and pay attention to the stones or silt staying in the pipe;
4. After the installation is completed, we need to conduct a pressure test for a period of time, and then check that there is no water leakage at each interface during the test, and replace it immediately if found.



Certificate



White Grey PVC Drainage Pipe 3 Inch For Hydroponic 5

White Grey PVC Drainage Pipe 3 Inch For Hydroponic 6

White Grey PVC Drainage Pipe 3 Inch For Hydroponic 7

Company Profile



High Mountain Pipe is a well-known PVC pipe manufacturer and wholesaler in Jiangsu. It produces multi-caliber HDPE pipes, pvc pipes, pvc hoses and accessories and supporting machines. The products are widely used. It is the first choice for watering and irrigation of agricultural and forestry breeding gardens. The pipeline is An essential transmission tool for industrial, agricultural, and construction engineering drainage cleaning. Complete specifications, can be customized according to customer needs, use quality to create a brand, and use service to win trust.



The company adheres to the people-oriented scientific development concept, correctly grasps product development trends, implements strategic target management, is committed to developing core manufacturing advantages, optimizing resource allocation and technological breakthroughs, introducing market-oriented and refined operating systems, achieving leapfrog development, and striving to build " "Rongchengxing" brand, implement a win-win strategy, and work hard for the development of the industry!



White Grey PVC Drainage Pipe 3 Inch For Hydroponic 8      White Grey PVC Drainage Pipe 3 Inch For Hydroponic 9



White Grey PVC Drainage Pipe 3 Inch For Hydroponic 10      White Grey PVC Drainage Pipe 3 Inch For Hydroponic 11





FAQ



Q: How and when can I receive my goods after payment?
A: For small batch products, they will be delivered to you by international express (DHL, FedEx, TNT, etc.) or by air. It usually takes 3-5 days to receive the goods after delivery. For high-volume products, it is worthwhile to see the goods and deliver them. It takes several days to several weeks to reach the destination port, depending on the location of the port.



Q: Is it possible to use the label or packaging I specified?
A: Yes. If necessary, we would like to use labels or packaging according to your requirements.



Q: Why choose us?
A: We are a professional manufacturer with competitive price, excellent quality and fast delivery time.
