25 HDPE 32 PE Water Pipe 50 Irrigation Agricultural Gardening Threading Pipe 1 Inch Drinking Water Pipe
----------------------------------------
Basic Info.
HDPE pipe is a high-density polyethylene pipe, the material is "HDPE", the abbreviation of "High Density Polyethylene". HDPE is a highly crystalline, non-polar thermoplastic resin. The appearance of the original HDPE is milky white, and the thin section is translucent to a certain extent.
PE pipe is a polyethylene plastic pipe. PE is the most basic type of plastic and has excellent resistance to most domestic and industrial chemicals. PE pipe can be divided into low density polyethylene pipe, medium density polyethylene pipe and high density polyethylene pipe
| SDR26 | SDR21 | SDR17 | SDR13.6 | SDR11 | |||||
| Pressure 0.6Mpa | Pressure 0.8Mpa | Pressure 1.0Mpa | Pressure 1.25Mpa | Pressure 1.6Mpa | |||||
| Outer diameter mm | Thick mm | Outer diameter mm | Thick mm | Outer diameter mm | Thick mm | Outer diameter mm | Thick mm | Outer diameter mm | Thick mm |
| 110 | 4.2 | 90 | 4.3 | 75 | 4.5 | 63 | 4.7 | 20 | 2.3 |
| 125 | 4.8 | 110 | 5.3 | 90 | 5.4 | 75 | 5.6 | 25 | 2.3 |
| 140 | 5.4 | 125 | 6 | 110 | 6.6 | 90 | 6.7 | 32 | 3 |
| 160 | 6.2 | 140 | 6.7 | 125 | 7.4 | 110 | 8.1 | 40 | 3.7 |
| 180 | 6.9 | 160 | 7.7 | 140 | 8.3 | 125 | 9.2 | 50 | 4.6 |
| 200 | 7.7 | 180 | 8.6 | 160 | 9.5 | 140 | 10.3 | 63 | 5.8 |
| 225 | 8.6 | 200 | 9.6 | 180 | 10.7 | 160 | 10.8 | 75 | 6.8 |
| 250 | 9.6 | 225 | 10.8 | 200 | 11.9 | 180 | 13.3 | 90 | 8.2 |
| 280 | 10.7 | 250 | 11.9 | 225 | 13.4 | 200 | 14.7 | 110 | 10 |
| 315 | 12.1 | 280 | 13.4 | 250 | 14.8 | 225 | 16.6 | 125 | 11.4 |
| 355 | 13.6 | 315 | 15 | 280 | 16.6 | 250 | 18.4 | 140 | 12.7 |
| 400 | 15.3 | 355 | 16.9 | 315 | 18.7 | 280 | 20.6 | 160 | 14.6 |
| 450 | 17.2 | 400 | 19.1 | 355 | 21.1 | 315 | 23.2 | 180 | 16.4 |
| 500 | 19.1 | 450 | 21.5 | 400 | 23.7 | 355 | 26.1 | 200 | 18.2 |
| 560 | 21.4 | 500 | 23.9 | 450 | 26.7 | 400 | 29.4 | 225 | 20.5 |
| 630 | 24.1 | 560 | 26.7 | 500 | 29.7 | 450 | 33.1 | 250 | 22.7 |
| 710 | 27.2 | 630 | 30 | 560 | 33.2 | 500 | 36.8 | 280 | 25.4 |
| 800 | 30.6 | 710 | 33.9 | 630 | 37.4 | 560 | 41.2 | 315 | 28.6 |
| 900 | 34.4 | 800 | 38.1 | 710 | 42.1 | 630 | 46.3 | 355 | 32.2 |
| 1000 | 38.2 | 900 | 42.9 | 800 | 47.4 | 710 | 52.2 | 400 | 36.3 |
| 1200 | 45.9 | 1000 | 47.7 | 900 | 53.3 | 800 | 58.8 | 450 | 40.9 |
| 1200 | 57.2 | 1000 | 59.3 | 500 | 45.4 | ||||
| 560 | 50.8 | ||||||||
| 630 | 57.3 | ||||||||
Advantage
High-density polyethylene has good heat resistance and cold resistance, good chemical stability, high rigidity and toughness, and good mechanical strength. Dielectric properties and environmental stress cracking resistance are also good. Hardness, tensile strength and creep are better than low-density polyethylene; abrasion resistance, electrical insulation, toughness and cold resistance are all better, but slightly worse than low-density insulation; good chemical stability, at room temperature Under the conditions, it is insoluble in any organic solvents, resistant to corrosion by acids, alkalis and various salts; the film has low permeability to water vapor and air, and low water absorption.
Details
Application
1. Urban tap water pipe network system.
2. Urban and rural drinking water pipelines.
3. Material and liquid transportation pipelines in chemical, chemical fiber, food, forestry, printing and dyeing, pharmaceutical, light industry, papermaking, metallurgical and other industries.
4. Agricultural irrigation pipes.
5. Protection sleeves for post and telecommunications lines and power wires.
6. Mine mortar conveying pipeline.
Certificate
Company Profile
High Mountain Pipe is a high-tech enterprise integrating R&D, production and sales, specializing in the production of ultra-high molecular weight polyethylene pipes, tunnel escape pipes, steel belt reinforced polyethylene (HDPE) spiral corrugated pipes, HDPE pipes, internal and external plastic-coated composite steel pipes, 3PE anticorrosion A series of multi-specification pipe products such as pipelines, gas station oil pipelines, oil well pipes, MPP power pipes, etc. The company always adheres to the concept of "innovation, efficiency, and integrity", absorbs new ideas, strictly controls quality, follows up all-round services, and insists on making high-quality products. Adhering to the tenet of "pursuing and creating brilliance", we provide solid and reliable guarantee and support for customers' production and operation. Become a reliable partner for the majority of users. Relying on the company's resources, the products are sold all over the country, and exported to Brazil, the Philippines, Australia, the United States, Mexico, South Africa and other countries, and have won unanimous praise from customers! Survive by quality, develop by reputation, we warmly welcome your patronage and sincerely look forward to serving you!
FAQ
Q: How to get free samples?
A: Send your address, telephone number, zip code and express account number to our mailbox, and tell us which model of samples you need. Our sales team will contact you within 24 hours.
Q: What are your payment terms?
A: Accept the T/T and L/C terms.
Q: What are raw materials?
A: PE
