PE Water Supply Pipe Black Large Diameter Agricultural Irrigation Pipe

10 Meter/Meters
MOQ
0.5$/m(1~10m);0.43$/m(>1000m)
Price
PE Water Supply Pipe Black Large Diameter Agricultural Irrigation Pipe
Features Gallery Product Description Request A Quote
Features
Specifications
Brand Name: HAIYANG
Model Number: HM1-71
Specification: DN80-2600mm
Color: Black,grey,or At Request
Usage: Water Supply
Raw Material: Carbon, Silicon, Manganese, Sulfur, Phosphorus, Magnesium,
Size: Customized Size
Standard: GB/T13295-2013 ISO2531/2003
Sample: Provide Sample
Advantage: High Quality
Length: As Costomer Requirements
High Light:

Dn300 Water Drainage Pipe

,

Dn400 Water Drainage Pipe

,

Ductile Iron Class K9 Pipes

Basic Infomation
Place of Origin: China
Brand Name: HWHP
Certification: ISO9001
Model Number: HM1-71
Payment & Shipping Terms
Packaging Details: 6m or 12m per piece
Supply Ability: 5000 Metric Ton/Metric Tons per Year
Product Description

PE Water Supply Pipe Black Large Diameter Agricultural Irrigation Pipe

----------------------------------------



Basic Info.



The main difference between HDPE water supply pipe and HDPE drainage pipe is their intended use. HDPE water supply pipes are designed for transporting potable water, while HDPE drainage pipes are meant for transporting wastewater. Both types of pipe are made from high-density polyethylene (HDPE), but HDPE water supply pipes have a higher level of purity than HDPE drainage pipes. This means that HDPE water supply pipes are safe for human contact, while HDPE drainage pipes should not be used for drinking water.



Diameter(mm) Outer diameter(mm) Wall thickness
(mm)
Weight/m
(kg)
Weight/root(kg) Root/km Weight/km(ton)
80 98 6 12.2 76.5 167 12.77
100 118 6.1 15.1 95 167 15.87
150 170 6.3 22.8 144 167 20.05
200 220 6.4 30.6 194 167 32.4
250 274 6.8 40.2 255 167 42.59
300 326 7.2 50.8 323 167 53.94
350 378 7.7 63.2 403 167 67.3
400 429 8.1 75.5 482 167 80.48
450 480 8.6 89.3 575 167 95.86
500 532 9 104.3 669 167 111.72
600 635 9.9 137.3 882 167 147.29
700 738 10.8 173.9 1123 167 187.54
800 842 11.7 215.2 1394 167 232.8
900 945 12.6 260.2 1691 167 282.4
1000 1048 13.5 309.3 2017 167 336.84
1200 1255 15.3 420.1 2758 167 460.69





Advantage



Good hygienic performance: no heavy metal salt stabilizer is added during the processing of PE pipe, the material is non-toxic, no scaling layer, no bacteria breeding,
A good solution to the secondary pollution of urban drinking water.
Excellent corrosion resistance: Except for a few strong oxidants, it can resist the erosion of various chemical media; no electrochemical corrosion.
Long service life: PE pipes can be safely used for more than 50 years under rated temperature and pressure conditions.
Good impact resistance: PE pipe has good toughness and high impact resistance, and heavy objects directly press through the pipeline, which will not cause the pipeline to break violently.
Reliable connection performance: The strength of the PE pipe hot melt or electrofusion interface is higher than that of the pipe body, and the joint will not move due to soil movement or live load effect is disconnected.
Good construction performance: the pipeline is light in weight, the welding process is simple, the construction is convenient, and the overall project cost is low.



Details



PE Water Supply Pipe Black Large Diameter Agricultural Irrigation Pipe 0     PE Water Supply Pipe Black Large Diameter Agricultural Irrigation Pipe 1PE Water Supply Pipe Black Large Diameter Agricultural Irrigation Pipe 2PE Water Supply Pipe Black Large Diameter Agricultural Irrigation Pipe 3



Application



Replaceable cement, cast iron and steel pipes
Industrial raw material pipeline
Landscaping water supply network
Pipes for sewage discharge
agricultural irrigation pipes
marine pipeline
Seawater desalination pipeline



Certificate



PE Water Supply Pipe Black Large Diameter Agricultural Irrigation Pipe 4

PE Water Supply Pipe Black Large Diameter Agricultural Irrigation Pipe 5

PE Water Supply Pipe Black Large Diameter Agricultural Irrigation Pipe 6

Company Profile



Our company's products are of high quality, and we always adhere to and implement the quality policy of "Quality is the foundation of a company's survival, and providing users with satisfactory products and services is our eternal pursuit". . Our company is a factory direct sale of ductile iron pipes, ductile iron pipe fittings, ductile iron manhole covers, Xinxing ductile pipes, ductile iron well grate; W type flexible cast iron pipe, W type cast iron drainage pipe and pipe fittings; A type flexible cast iron pipe, A type cast iron drainage Pipes and fittings, B-type flexible cast iron pipes, B-type cast iron drainage pipes and pipe fittings and other products. Our company is a group company integrating production and sales. The annual production capacity of ductile iron pipes and flexible drainage pipes is 300,000 tons; the annual sales volume of ductile iron pipes is 120,000 tons and the annual sales volume of flexible drainage pipes is 180,000 tons.





PE Water Supply Pipe Black Large Diameter Agricultural Irrigation Pipe 7     PE Water Supply Pipe Black Large Diameter Agricultural Irrigation Pipe 8



PE Water Supply Pipe Black Large Diameter Agricultural Irrigation Pipe 9     PE Water Supply Pipe Black Large Diameter Agricultural Irrigation Pipe 10



FAQ



Q: What is the delivery time?
A: We always have common products in stock and can be shipped within 30 days.
Large orders require 15 days to complete production.



Q: How to get free samples?
A: Send your address, telephone number, zip code and express account number to our mailbox, and tell us which model of samples you need. Our sales team will contact you within 24 hours.



Q: Can I customize the size I need?
A: Yes
