20mm 25mm 32mm 40mm 50mm 63mm HDPE Pipe For Water Supply And Drainage

10 Meter/Meters
MOQ
0.5$/m(1~10m);0.43$/m(>1000m)
Price
20mm 25mm 32mm 40mm 50mm 63mm HDPE Pipe For Water Supply And Drainage
Features Gallery Product Description Request A Quote
Features
Specifications
Brand Name: BAILUN
Model Number: HM07018
Specification: DN20-DN1100mm
Color: White Or At Request
Usage: Water Supply
Raw Material: PE
Size: Customized Size
Working Pressure: 1.25mpa-2.5mpa
Sample: Provide Sample
Advantage: High Quality
Length: As Costomer Requirements
High Light:

20mm Polypropylene Random Copolymer Pipe

,

32mm PPR Hot And Cold Water Pipe

,

25 gauge PPR Pipe For Water Supply

Basic Infomation
Place of Origin: China
Brand Name: HWHP
Certification: ISO9001
Model Number: HM07018
Payment & Shipping Terms
Packaging Details: 100m or 40m per piece
Supply Ability: 5000 Metric Ton/Metric Tons per Year
Product Description

20mm 25mm 32mm 40mm 50mm 63mm HDPE Pipe For Water Supply And Drainage

----------------------------------------

Basic Info.



Can HDPE Pipe Be Used for Hot Water?
HDPE pipes exhibit excellent thermal properties, making them suitable for a wide range of temperatures. They can handle both cold and hot water, adding to their versatility in water distribution systems. The material remains robust and resilient even when exposed to elevated temperatures, making HDPE pipes a reliable choice for transporting hot water.
The thermal properties of HDPE pipes make them particularly advantageous in applications where the temperature of the transported water fluctuates. Whether it's for residential plumbing systems or industrial processes requiring hot water, HDPE pipes offer a dependable solution.





Size PN2.0MPa PN1.6MPa PN1.25MPa PN1.0MPa PN0.8MPa PN0.6MPa
SDR 9 SDR 11 SDR 13.6 SDR 17 SDR 21 SDR 26
OD(mm) thickness thickness thickness thickness thickness thickness
20 2.3 2.3
25 3.0 2.3 2.3
32 3.6 3.0 2.4
40 4.5 3.7 3.0 2.4
50 5.6 4.6 3.7 3.0
63 7.1 5.8 4.7 3.8
75 8.4 6.8 5.6 4.5
90 10.1 8.2 6.7 5.4 4.3
110 12.3 10.0 8.1 6.6 5.3 4.2
125 14.0 11.4 9.2 7.4 6.0 4.8
140 15.7 12.7 10.3 8.3 6.7 5.4
160 17.9 14.6 11.8 9.5 7.7 6.2
180 20.1 16.4 13.3 10.7 8.6 6.9
200 22.4 18.2 14.7 11.9 9.6 7.7
225 25.2 20.5 16.6 13.4 10.8 8.6
250 27.9 22.7 18.4 14.8 11.9 9.6
280 31.3 25.4 20.6 16.6 13.4 10.7
315 35.2 28.6 23.2 18.7 15.0 12.1
355 39.7 32.2 26.1 21.1 16.9 13.6
400 44.7 36.3 29.4 23.7 19.1 15.3
450 50.3 40.9 33.1 26.7 21.5 17.2
500 55.8 45.4 36.8 29.7 23.9 19.1
560 62.5 50.8 41.2 33.2 26.7 21.4
630 70.3 57.2 46.3 37.4 30.0 24.1
710 79.3 64.5 52.2 42.1 33.9 27.2
800 89.3 72.6 58.8 47.4 38.1 30.6
900   81.8 66.2 53.3 42.9 34.4
1000   90.2 72.5 59.3 47.7 38.2
1200     88.2 67.9 57.2 45.9
1400     102.9 82.4 66.7 53.5
1500     110.2 88.2 71.4 57.6
1600     117.6 94.1 76.2 61.2

Advantage

Good hygienic performance: no heavy metal salt stabilizer is added during the processing of PE pipe, the material is non-toxic, no scaling layer, no bacteria breeding,
A good solution to the secondary pollution of urban drinking water.
Excellent corrosion resistance: Except for a few strong oxidants, it can resist the erosion of various chemical media; no electrochemical corrosion.
Long service life: PE pipes can be safely used for more than 50 years under rated temperature and pressure conditions.
Good impact resistance: PE pipe has good toughness and high impact resistance, and heavy objects directly press through the pipeline, which will not cause the pipeline to break violently.



Details

20mm 25mm 32mm 40mm 50mm 63mm HDPE Pipe For Water Supply And Drainage 020mm 25mm 32mm 40mm 50mm 63mm HDPE Pipe For Water Supply And Drainage 120mm 25mm 32mm 40mm 50mm 63mm HDPE Pipe For Water Supply And Drainage 220mm 25mm 32mm 40mm 50mm 63mm HDPE Pipe For Water Supply And Drainage 3



Application

Urban water pipe network system
Replaceable cement, cast iron and steel pipes
Industrial raw material pipeline
Landscaping water supply network
Pipes for sewage discharge
agricultural irrigation pipes
marine pipeline
Seawater desalination pipeline



Certificate



20mm 25mm 32mm 40mm 50mm 63mm HDPE Pipe For Water Supply And Drainage 4

20mm 25mm 32mm 40mm 50mm 63mm HDPE Pipe For Water Supply And Drainage 5

20mm 25mm 32mm 40mm 50mm 63mm HDPE Pipe For Water Supply And Drainage 6

Company Profile



High Mountain Pipe is a production enterprise focusing on core technology of pipelines.

The company introduced advanced production equipment and manufacturing technology, and successively developed grooved (HDPE) high-density polyethylene mute, HDPE grooved mute pipe, HDPE grooved drainage pipe compression drainage system and high-density polyethylene siphon drainage system. Series products.



20mm 25mm 32mm 40mm 50mm 63mm HDPE Pipe For Water Supply And Drainage 7 20mm 25mm 32mm 40mm 50mm 63mm HDPE Pipe For Water Supply And Drainage 8



20mm 25mm 32mm 40mm 50mm 63mm HDPE Pipe For Water Supply And Drainage 9 20mm 25mm 32mm 40mm 50mm 63mm HDPE Pipe For Water Supply And Drainage 10



FAQ



Q: What are raw materials?
A: PE



Q: How to get free samples?
A: Send your address, telephone number, zip code and express account number to our mailbox, and tell us which model of samples you need. Our sales team will contact you within 24 hours.



Q: What is your minimum order quantity?
A: Accessories: one box or one bag.
Pipeline: 200~5000 meters/size, depending on different sizes.
