Hdpe Pipe Fittings Large Diameter Pipe Elbow Sylphon Bellows Fittings
10 Meter/Meters
MOQ
0.5$/m(1~10m);0.43$/m(>1000m)
Price
Hdpe Pipe Fittings Large Diameter Pipe Elbow Sylphon Bellows Fittings
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: China
Brand Name: HWHP
Certification: ISO9001
Model Number: HM04007-10
High Light:

large diameter poly pipe elbow

,

pe100 poly pipe elbow

Payment & Shipping Terms
Packaging Details: 6m or 12m per piece
Supply Ability: 5000 Metric Ton/Metric Tons per Year
Specifications
Brand Name: HAIYANG
Model Number: HM04007-10
Specification: 20-800mm,or As Custom
Color: Black Or As Custom
Usage: HDPE Pipe Connector
Raw Material: PE100
Size: Customized Size
MOQ: 1 Piece
Sample: Provide Samples
Advantage: High Performance
Occasion: House Service,water Mains,irrigation,various
Product Description

HDPE Pipe Fittings Large Diameter Pipe Elbow Sylphon Bellows Fittings

----------------------------------------



Basic Info.



HDPE drainage pipe is a thermoplastic pipe material, the matrix is ​​mainly high-density polyethylene resin, and it is used for plastic pipes without internal pressure after extrusion molding. The raw material is white powder or granular, non-toxic, tasteless, and has the advantages of corrosion resistance, aging resistance, impact resistance and crack resistance.HDPE has good electrical properties, especiallyhigh dielectric strength, medium to high molecular weight,and excellent impact resistance, both at room temperatureand even at low temperatures.HDPE (high density Polyethylene) pipes are supplied to China's municipal pipe market. Plastic pipes are developing steadily. PE pipes, PP-R pipes, and UPVC pipes all occupy a place.



Outer Diameter
DN (mm)
SDR 9
PN20
SDR 11
PN16
SDR 13.6
PN12.5
SDR 17
PN10
SDR21
PN8
SDR26
PN6
  Wall Thick Ness(mm)
20 2.3 2.3
25 3 2.3 2.3
32 3.6 3 2.4
40 4.5 3.7 3 2.4
50 5.6 4.6 3.7 3
63 7.1 5.8 4.7 3.8
75 8.4 6.8 5.6 4.5
90 10.1 8.2 6.7 5.4 4.3
110 12.3 10 8.1 6.6 5.3 4.2
125 14 11.4 9.2 7.4 6 4.8
140 15.7 12.7 10.3 8.3 6.7 5.4
160 17.9 14.6 11.8 9.5 7.7 6.2
180 20.1 16.4 13.3 10.7 8.6 6.9
200 22.4 18.2 14.7 11.9 9.6 7.7
225 25.2 20.5 16.6 13.4 10.8 8.6
250 27.9 22.7 18.4 14.8 11.9 9.6
280 31.3 25.4 20.6 16.6 13.4 10.7
315 35.2 28.6 23.2 18.7 15 12.1
355 39.7 32.2 26.1 21.1 16.9 13.6
400 44.7 36.3 29.4 23.7 19.1 15.3
450 50.3 40.9 33.1 26.7 21.5 17.2
500 55.8 45.4 36.8 29.7 23.9 19.1
560 62.5 50.8 41.2 33.2 26.7 21.4
630 70.3 57.2 46.3 37.4 30 24.1
710   64.5 52.2 42.1 33.9 27.2
800   72.7 58.8 47.4 38.1 30.6
900   81.8 66.2 53.3 42.9 34.4
1000   90.2 72.5 59.3 47.7 38.2
1200     88.2 67.9 57.2 45.9
1400     102.9 82.4 66.7 53.5
1500     110.2 88.2 71.4 57.6
1600     117.6 94.1 76.2

61.2



Hdpe Pipe Fittings Large Diameter Pipe Elbow Sylphon Bellows Fittings 0



Advantage



1. Flexibility: Because PE-RT is relatively soft. Therefore, no special tools are required during construction, so the construction cost is relatively low.
2. Thermal conductivity: pipes used for floor heating need to have good thermal conductivity. PE-RT has better thermal conductivity, and its thermal conductivity is twice that of PP-R and PP-B pipes. It is very suitable for floor heating.
3. High temperature resistance: The high temperature resistance of PE-RT can reach 90°C, while that of PEX can only reach 65°C.
4. Low temperature thermal shock resistance: PE-RT has better low temperature shock resistance. During winter construction, the pipes are not susceptible to impact and rupture, which increases the flexibility of construction arrangements.
5. Environmental protection: PE-RT and PP-R can be recycled and will not pollute the environment. The PEX cannot be recycled will cause secondary pollution;



Details



     Hdpe Pipe Fittings Large Diameter Pipe Elbow Sylphon Bellows Fittings 1Hdpe Pipe Fittings Large Diameter Pipe Elbow Sylphon Bellows Fittings 2Hdpe Pipe Fittings Large Diameter Pipe Elbow Sylphon Bellows Fittings 3Hdpe Pipe Fittings Large Diameter Pipe Elbow Sylphon Bellows Fittings 4






Application


1.Urban and rural drinking water pipelines.
2.Material and liquid transportation pipelines in chemical, chemical fiber, food, forestry, printing and dyeing, pharmaceutical, light industry, papermaking, metallurgical and other industries.
3. Agricultural irrigation pipes.
4. Protection sleeves for post and telecommunications lines and power wires.
5. Mine mortar conveying pipeline.
6. Protection sleeves for post and telecommunications lines and power wires.



Certificate



Hdpe Pipe Fittings Large Diameter Pipe Elbow Sylphon Bellows Fittings 5

Hdpe Pipe Fittings Large Diameter Pipe Elbow Sylphon Bellows Fittings 6

Hdpe Pipe Fittings Large Diameter Pipe Elbow Sylphon Bellows Fittings 7



Company Profile



High Mountain Pipe is a specialized enterprise that produces anticorrosive plastic (pp, frpp, pe, hdpe, pvdf, pph, upvc, cpvc, abs) pipes, fittings, plates, and valves. The company's pipe production diameter is up to 1200mm, and the plate production width is up to 2000mm, and the length is unlimited. In 2006, the company passed ISO9001-2000 quality management system certification, ISO14001 environmental system certification, OHSA18001 occupational health and safety system certification, CMMI certification, and IEC27001 information security system certification.



The company has passed ISO 9001, ISO 14001, OHSAS 18001 management system certification and China environmental labeling product certification. The company is applying for CQC (China Quality) certification and CNAS (China National Accreditation Service for Conformity Assessment) national laboratory qualification accreditation. The company adheres to the business philosophy of "integrity, modesty, and a long history",Relying on our wide business channels and professional experience, we are more skillfully providing products of stable but differentiated quality, along with flexible, highly efficient & considerate service to satisfy our partner at more competitive pricing.



Hdpe Pipe Fittings Large Diameter Pipe Elbow Sylphon Bellows Fittings 8      Hdpe Pipe Fittings Large Diameter Pipe Elbow Sylphon Bellows Fittings 9



Hdpe Pipe Fittings Large Diameter Pipe Elbow Sylphon Bellows Fittings 10      Hdpe Pipe Fittings Large Diameter Pipe Elbow Sylphon Bellows Fittings 11



FAQ



Q: Why choose us?
A: We are a professional manufacturer with more competitive price, fast delivery time and excellent quality.



Q: Which payment method can your company use?
A: T/T, L/C or full trade insurance. You can choose the one that is convenient for you.



Q: How and when can I receive my goods after payment?
A: For small batch products, they will be delivered to you by international express (DHL, FedEx, TNT, etc.) or by air. It usually takes 3-5 days to receive the goods after delivery. For high-volume products, it is worthwhile to see the goods and deliver them. It takes several days to several weeks to reach the destination port, depending on the location of the port.
