Water Supply PVC Drainage Pipe Fittings Quickly Connect Sewage Tube
10 Meter/Meters
MOQ
0.5$/m(1~10m);0.43$/m(>1000m)
Price
Water Supply PVC Drainage Pipe Fittings Quickly Connect Sewage Tube
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: China
Brand Name: HWHP
Certification: ISO9001
Model Number: HM06004-1
High Light:

DN 800mm PVC Sewage Tube Fittings

,

Water Supply PVC Drainage Pipe Fittings

,

PVC Sewage Tube Fittings

Payment & Shipping Terms
Packaging Details: 6m or 12m per piece
Supply Ability: 5000 Metric Ton/Metric Tons per Year
Specifications
Brand Name: HAIYANG
Model Number: HM06004-1
Specification: DN20-DN800mm
Color: Black,white,grey,green Or At Request
Usage: Water Supply
Raw Material: PVC
Size: Customized Size
Working Pressure: 0.2mpa-2.5mpa
Sample: Provide Sample
Advantage: High Quality
Length: As Costomer Requirements
Product Description

Water Supply And Drainage Pipes PVC Drainage Pipe Fittings Quickly Connect Sewage Pipes

----------------------------------------



Basic Info.



The common PVC water supply pipes in the market are mainly gray. The wall of the same specification is thicker than that of PVC drainage pipes, and the impact resistance is much greater than that of PVC drainage pipes. Although the rigidity of PVC water supply pipe itself is relatively large, the low temperature pressure resistance is excellent, and the pressure ring stress at 20°C can be greater than 42 MPa, which is the largest amount of water supply plastic pipes for construction on the market, but its high temperature pressure resistance is very poor. Therefore, it can only be used in cold water or low-temperature hot water pipe systems below 60°C.



DN.mm Wall thickness(mm)
0.63 M pa 0.8Mpa l.OMpa 1.25Mpa 1.6Mpa 2.0Mpa
20 - - - - 2.0 2.0
25 - - - - 2.0 2.0
32 - - - - 2.0 2.0
40 - - - - 2.0 2.0
50 - - - - 2.0 2.4
50 - - - 2.0 2.4 3.0
63 - - 2.0 2.5 3.0 3.8
75 - 2.0 2.3 2.9 3.6 4.5
90 2.0 2.2 2.8 3.5 4.3 6.5
110 2.2 2.7 3.4 4.2 5.3 6.6
125 2.5 3.1 3.9 4.8 6.0 7.4
140 2.8 3.5 4.3 5.4 6.7 8.3
160 3.2 4.0 4.9 6.2 7.7 9.5
180 3.6 4.4 5.5 6.9 8.6 10.7
200 3.9 4.9 6.2 7.7 9.6 11.9
225 4.4 5.5 6.9 8.6 10.8 13.4
250 4.9 6.2 7.7 9.6 11.9 14.8
280 5.5 6.9 8.6 10.7 13.4 16.6
315 6.2 7.7 9.7 12.1 15.0 18.7
355 7.0 8.7 10.9 13.6 16.9 21.1
400 7.9 9.8 12.3 15.3 19.1 23.7
450 8.8 11.0 13.8 17.2 21.5 26.7
500 8.9 12.3 15.3 19.1 23.9 29.7
560 11.0 13.7 17.2 21.4 26.7 33.2
630 12.3 15.4 19.3 24.1 30.0 37.4



Water Supply PVC Drainage Pipe Fittings Quickly Connect Sewage Tube 0



Advantage



1. It has good tensile and compressive strength.
2. The wall of the pipe is very smooth, so the resistance of the water flow is very small. Its water delivery capacity is 20% higher than that of the cast iron pipe of the same diameter, and the water delivery effect is very high.
3. Corrosion resistance and chemical resistance are also very good, with good acid resistance, alkali resistance, corrosion resistance, not affected by wet moisture and soil pH, and have a long service life.
4. It has good water tightness. Whether this kind of pipe is connected by bonding or rubber ring, it can maintain good water tightness.
5. It has good stretchability and thermal stability, can adapt to different environments and has a wide range of use.
6. With good hardness, it can be used as a drainage pipe, which can prevent the erosion of insects and ants, and has a longe
r service life.



Details

 Water Supply PVC Drainage Pipe Fittings Quickly Connect Sewage Tube 1Water Supply PVC Drainage Pipe Fittings Quickly Connect Sewage Tube 2Water Supply PVC Drainage Pipe Fittings Quickly Connect Sewage Tube 3Water Supply PVC Drainage Pipe Fittings Quickly Connect Sewage Tube 4






Application



Water supply pipes, household pipes, house wall panels, commercial machine casings, electronic product packaging, medical equipment, food packaging, etc.



Certificate



Water Supply PVC Drainage Pipe Fittings Quickly Connect Sewage Tube 5

Water Supply PVC Drainage Pipe Fittings Quickly Connect Sewage Tube 6

Water Supply PVC Drainage Pipe Fittings Quickly Connect Sewage Tube 7

Company Profile



High Mountain Pipe is a well-known PVC pipe manufacturer and wholesaler in Jiangsu. It produces multi-caliber HDPE pipes, pvc pipes, pvc hoses and accessories and supporting machines. The products are widely used. It is the first choice for watering and irrigation of agricultural and forestry breeding gardens. The pipeline is An essential transmission tool for industrial, agricultural, and construction engineering drainage cleaning. Complete specifications, can be customized according to customer needs, use quality to create a brand, and use service to win trust.



The company adheres to the people-oriented scientific development concept, correctly grasps product development trends, implements strategic target management, is committed to developing core manufacturing advantages, optimizing resource allocation and technological breakthroughs, introducing market-oriented and refined operating systems, achieving leapfrog development, and striving to build " "Rongchengxing" brand, implement a win-win strategy, and work hard for the development of the industry!



Water Supply PVC Drainage Pipe Fittings Quickly Connect Sewage Tube 8      Water Supply PVC Drainage Pipe Fittings Quickly Connect Sewage Tube 9



Water Supply PVC Drainage Pipe Fittings Quickly Connect Sewage Tube 10      Water Supply PVC Drainage Pipe Fittings Quickly Connect Sewage Tube 11





FAQ



Q: How to buy products?
A: Send an email to us and we will get back to you within one day.



Q: Can you make special designs and logos on your products?
A: Yes, it is very easy.



Q: Why choose us?
A: We are a professional manufacturer with competitive price, excellent quality and fast delivery time.
