Black Color Hdpe Water Supply Drainage Sewage Pipe Irrigation DN25mm Crack Resistance

10 Meter/Meters
MOQ
0.5$/m(1~10m);0.43$/m(>1000m)
Price
Black Color Hdpe Water Supply Drainage Sewage Pipe Irrigation DN25mm Crack Resistance
Features Gallery Product Description Request A Quote
Features
Specifications
Brand Name: HAIYANG
Model Number: HM1
Specification: DN25mm-1000mm
Color: Black Or Customer Request
Usage: Water Supply
Raw Material: PE100
Size: Customized Size
MOQ: 100 Meters
Sample: Provide Samples
Advantage: High Performance
High Light:

Hdpe Water Supply Drainage Irrigation Pipe

,

Black DN25mm Hdpe Water Supply Pipe

,

Crack resistance Hdpe Water Supply Pipe

Basic Infomation
Place of Origin: China
Brand Name: HWHP
Certification: ISO9001
Model Number: HM1
Payment & Shipping Terms
Packaging Details: 6m or 12m per piece
Supply Ability: 5000 Metric Ton/Metric Tons per Year
Product Description

High Quality HDPE Water Supply And Drainage Plastic Pipe Prices Sewage Pipe

----------------------------------------

Basic Info.



HDPE pipe is a highly crystalline, non-polar thermoplastic resin. Generally, the application range of PE pipes for water supply pipelines is below 40°C, and cannot be used for hot water delivery pipelines. The appearance of the original HDPE is milky white, and it is translucent to a certain extent in the thin section. PE pipe material has excellent resistance to most household and industrial chemicals. Certain types of chemicals are chemically aggressive, such as corrosive oxidants (concentrated nitric acid), aromatic hydrocarbons (xylene), and halogenated hydrocarbons (carbon tetrachloride).

The main features of HDPE pipes are: good toughness and flexibility; small friction coefficient and strong passing ability; convenient construction, good chemical stability, long service life, suitable deflection, good resistance to rapid crack transmission, resistance to Low temperature, conform to the requirements of the times, "green" environmental protection.





Outer Diameter
DN (mm)
SDR 9
PN20
SDR 11
PN16
SDR 13.6
PN12.5
SDR 17
PN10
SDR21
PN8
SDR26
PN6
Packing
Loaded into 40GP/Piece
6m or 12m per Piece
  Wall Thick Ness(mm) Wall Thick Ness(mm) Wall Thick Ness(mm) Wall Thick Ness(mm) Wall Thick Ness(mm) Wall Thick Ness(mm)
75 8.4 6.8 5.6 4.5     1085
90 10.1 8.2 6.7 5.4 4.3   754
110 12.3 10 8.1 6.6 5.3 4.2 504
125 14 11.4 9.2 7.4 6 4.8 378
140 15.7 12.7 10.3 8.3 6.7 5.4 304
160 17.9 14.6 11.8 9.5 7.7 6.2 224
180 20.1 16.4 13.3 10.7 8.6 6.9 182
200 22.4 18.2 14.7 11.9 9.6 7.7 143
225 25.2 20.5 16.6 13.4 10.8 8.6 110
250 27.9 22.7 18.4 14.8 11.9 9.6 90
280 31.3 25.4 20.6 16.6 13.4 10.7 72
315 35.2 28.6 23.2 18.7 15 12.1 56
355 39.7 32.2 26.1 21.1 16.9 13.6 42
400 44.7 36.3 29.4 23.7 19.1 15.3 30
450 50.3 40.9 33.1 26.7 21.5 17.2 25
500 55.8 45.4 36.8 29.7 23.9 19.1 20
560 62.5 50.8 41.2 33.2 26.7 21.4 16
630 70.3 57.2 46.3 37.4 30 24.1 12
710   64.5 52.2 42.1 33.9 27.2 9
800   72.7 58.8 47.4 38.1 30.6 6
900   81.8 66.2 53.3 42.9 34.4 6
1000   90.2 72.5 59.3 47.7 38.2 4
1200     88.2 67.9 57.2 45.9
1400     102.9 82.4 66.7 53.5
1500     110.2 88.2 71.4 57.6
1600     117.6 94.1 76.2 61.2





Advantage


1. Crack resistance
HDPE pipe is stable in structure, not easy to be damaged and cracked, and has a low price. It can effectively reduce noise. It has been gradually applied in building wiring, household appliances, communication equipment, etc.
2. Impact resistance
1) The special structure of HDPE pipe makes it have high mechanical strength and high ring stiffness, and can withstand strong impacts more strongly than traditional pipes, such as areas with multiple earthquakes.
2), the low temperature resistance of HDPE pipe, strong ductility, not easy to be brittle, can resist the impact of extremely cold weather, such as northern China.
3. Wear resistance
The high polymer composition of HDPE pipe is the main reason for its high wear resistance. The wear resistance is even higher than that of most metals, and the self-lubrication is good. It is an ideal pipe.





Details

Black Color Hdpe Water Supply Drainage Sewage Pipe Irrigation DN25mm Crack Resistance 0Black Color Hdpe Water Supply Drainage Sewage Pipe Irrigation DN25mm Crack Resistance 1Black Color Hdpe Water Supply Drainage Sewage Pipe Irrigation DN25mm Crack Resistance 2Black Color Hdpe Water Supply Drainage Sewage Pipe Irrigation DN25mm Crack Resistance 3







Application



1. Good wear resistance, low wall friction coefficient, low flow resistance, and excellent conveying capacity.
2. A variety of non-excavation methods can be used, and the construction and installation are extremely convenient.
3. The system cost is low, and the maintenance cost is low, which can greatly reduce the project cost.


Certificate

Black Color Hdpe Water Supply Drainage Sewage Pipe Irrigation DN25mm Crack Resistance 4
Black Color Hdpe Water Supply Drainage Sewage Pipe Irrigation DN25mm Crack Resistance 5
Black Color Hdpe Water Supply Drainage Sewage Pipe Irrigation DN25mm Crack Resistance 6
Company Profile


High Mountain Pipe Industry is a high-tech enterprise integrating production and sales of sewage treatment equipment and municipal water supply and drainage pipelines. With a long-term vision and taking advantage of the background of Internet big data, we rely on our own production technology strength to continuously explore the transformation and upgrading strategies of traditional production enterprises, and become a new domestic "Internet + pipeline building material" production enterprise! The company integrates product development, production and sales.


The company takes "sunshine trading" as its corporate purpose; relying on a large number of production equipment, scientific production formula, staff team, and strong production force, it is committed to improving the quality of China's pipeline building materials, making prices more affordable, and making transactions more transparent.


Black Color Hdpe Water Supply Drainage Sewage Pipe Irrigation DN25mm Crack Resistance 7     Black Color Hdpe Water Supply Drainage Sewage Pipe Irrigation DN25mm Crack Resistance 8

Black Color Hdpe Water Supply Drainage Sewage Pipe Irrigation DN25mm Crack Resistance 9     Black Color Hdpe Water Supply Drainage Sewage Pipe Irrigation DN25mm Crack Resistance 10

FAQ



Q: Is the price on this page correct?
A: The listed prices are for reference only, please contact us directly for the latest prices.



Q: Is it possible to use the label or packaging I specified?
A: Yes. If necessary, we would like to use labels or packaging according to your requirements.



Q: Can you make special designs and logos on your products?
A: Yes, it is very easy.
