Durable HDPE Water Pipe Sdr 17 Hdpe Pipe High Quality Water Pipe
----------------------------------------
Basic Info.
How to distinguish between HDPE water supply pipe and HDPE drainage pipe?
HDPE water supply pipe and HDPE drainage pipe are both made of high-density polyethylene (HDPE), but they have different applications. HDPE water supply pipe is typically used for potable water distribution, while HDPE drainage pipe is typically used for sewer and stormwater systems. So, how can you tell the difference between HDPE water supply pipe and HDPE drainage pipe? Here are a few key differences: HDPE water supply pipe is usually thicker than HDPE drainage pipe. This is because it needs to be able to withstand higher pressures. HDPE water supply pipe is typically black, while HDPE drainage pipe is usually white. This is because different colored dyes are used to distinguish between the two types of pipe. HDPE water supply pipe has smooth interior walls, while HDPE drainage pipe has corrugated interior walls. This helps to improve the strength and flexibility of the pipe. If you're not sure which type of HDPE pipe you need, be sure to consult with a professional before making your purchase.
| Diameter(mm) | Outer diameter(mm) | Wall thickness (mm) |
Weight/m (kg) |
Weight/root(kg) | Root/km | Weight/km(ton) |
| 80 | 98 | 6 | 12.2 | 76.5 | 167 | 12.77 |
| 100 | 118 | 6.1 | 15.1 | 95 | 167 | 15.87 |
| 150 | 170 | 6.3 | 22.8 | 144 | 167 | 20.05 |
| 200 | 220 | 6.4 | 30.6 | 194 | 167 | 32.4 |
| 250 | 274 | 6.8 | 40.2 | 255 | 167 | 42.59 |
| 300 | 326 | 7.2 | 50.8 | 323 | 167 | 53.94 |
| 350 | 378 | 7.7 | 63.2 | 403 | 167 | 67.3 |
| 400 | 429 | 8.1 | 75.5 | 482 | 167 | 80.48 |
| 450 | 480 | 8.6 | 89.3 | 575 | 167 | 95.86 |
| 500 | 532 | 9 | 104.3 | 669 | 167 | 111.72 |
| 600 | 635 | 9.9 | 137.3 | 882 | 167 | 147.29 |
| 700 | 738 | 10.8 | 173.9 | 1123 | 167 | 187.54 |
| 800 | 842 | 11.7 | 215.2 | 1394 | 167 | 232.8 |
| 900 | 945 | 12.6 | 260.2 | 1691 | 167 | 282.4 |
| 1000 | 1048 | 13.5 | 309.3 | 2017 | 167 | 336.84 |
| 1200 | 1255 | 15.3 | 420.1 | 2758 | 167 | 460.69 |
Advantage
1. Unique flexibility and excellent scratch resistance
2. Very outstanding low temperature resistance
3. Good fracture toughness with rapid crack growth
4. Excellent corrosion resistance, better hygiene performance and longer service life
Details
Application
1. Municipal engineering water supply system
2. Building indoor water supply system
3. Outdoor buried water supply system and residential area
4. Buried water supply system in the plant
5. Old pipeline repair
6. Water treatment engineering piping system
7. Industrial water pipes in gardens, irrigation and other fields.
Certificate
Company Profile
Located in Jiangsu, with convenient water and land transportation. It is a comprehensive enterprise integrating research, development, design, application, production and sales. The company has production lines for PE water supply pipes with larger diameters, prestressed corrugated pipes, corrugated pipe production lines, PVC pipe production lines and other equipment. Specializing in the production of PE water supply pipes, prestressed corrugated pipes, HDPE corrugated pipes, plastic blind trenches, permeable pipes, etc. The products are mainly used in municipal administration, highways, railways, water conservancy, power, environmental greening and infrastructure construction, and are used in municipalities and expressways. Many national key projects such as railways and railways have been well received by engineering experts and users.
FAQ
Q: Where is your company?
A: We are located in Jiangsu, China.
Q: What is your warranty policy?
A: The product is guaranteed for two years from the date of shipment (or leaving the seller's factory depending on the terms).
It is also guaranteed that the product can be used for 50 years.
Q: How to buy products?
A: Send an email to us and we will get back to you within one day.
