HDPE Water Supply Pipes For Sustainable And Eco-Friendly Water Systems
----------------------------------------
Basic Info.
HDPE is a very common material, that is, high-density polyethylene. HD means high-density, so the name implies. It is harder than ordinary PE plastic, milky white, has good chemical stability, and has a certain high and low temperature resistance. If the process is hygienic, it is a relatively "clean" material. HDPE water supply pipes and PE water supply pipes are both PE pipe fittings. HDPE is high-density polyethylene, and PE is polyethylene. That's the difference. But the physical properties are different.
| Diameter(mm) | Outer diameter(mm) | Wall thickness (mm) |
Weight/m (kg) |
Weight/root(kg) | Root/km | Weight/km(ton) |
| 80 | 98 | 6 | 12.2 | 76.5 | 167 | 12.77 |
| 100 | 118 | 6.1 | 15.1 | 95 | 167 | 15.87 |
| 150 | 170 | 6.3 | 22.8 | 144 | 167 | 20.05 |
| 200 | 220 | 6.4 | 30.6 | 194 | 167 | 32.4 |
| 250 | 274 | 6.8 | 40.2 | 255 | 167 | 42.59 |
| 300 | 326 | 7.2 | 50.8 | 323 | 167 | 53.94 |
| 350 | 378 | 7.7 | 63.2 | 403 | 167 | 67.3 |
| 400 | 429 | 8.1 | 75.5 | 482 | 167 | 80.48 |
| 450 | 480 | 8.6 | 89.3 | 575 | 167 | 95.86 |
| 500 | 532 | 9 | 104.3 | 669 | 167 | 111.72 |
| 600 | 635 | 9.9 | 137.3 | 882 | 167 | 147.29 |
| 700 | 738 | 10.8 | 173.9 | 1123 | 167 | 187.54 |
| 800 | 842 | 11.7 | 215.2 | 1394 | 167 | 232.8 |
| 900 | 945 | 12.6 | 260.2 | 1691 | 167 | 282.4 |
| 1000 | 1048 | 13.5 | 309.3 | 2017 | 167 | 336.84 |
| 1200 | 1255 | 15.3 | 420.1 | 2758 | 167 | 460.69 |
Advantage
Wide range of applications: PE water pipes are not only suitable for tap water, industrial water, agricultural irrigation and other fields, but can also be used to transport liquefied gases, chemicals, etc.
Low maintenance costs: PE water pipes have excellent durability, long service life, and are not easily affected by external factors, so maintenance costs are low.
Convenient welding: PE water pipes can be connected using hot melt welding technology, which is simple to operate, firm in connection, and not easy to leak.
Safety and environmental protection: PE water pipes do not contain heavy metals and other harmful substances, comply with environmental protection standards, and are safe and reliable to use.
Details
Application
Medical and health field: PE water pipes can be used in medical and health fields, such as infusion pipes, hemodialysis pipes, etc.
Gas transportation system: PE water pipes can be used in gas transportation systems, such as urban gas pipelines, industrial gas pipelines, etc.
Underground drainage system: PE water pipes can be used in underground drainage systems, such as underground drainage pipes, rainwater collection pipes, etc.
Power communication field: PE water pipes can be used in the power communication field, such as cable protection pipes, optical cable protection pipes, etc.
Construction engineering field: PE water pipes can be used in construction engineering fields, such as water pipes inside buildings, water pipes in fire protection systems, etc.
Fishery farming field: PE water pipes can be used in fishery farming fields, such as aquaculture, seaweed farming, etc.
Certificate
Company Profile
Located in Jiangsu, with convenient water and land transportation. It is a comprehensive enterprise integrating research, development, design, application, production and sales. The company has production lines for PE water supply pipes with larger diameters, prestressed corrugated pipes, corrugated pipe production lines, PVC pipe production lines and other equipment. Specializing in the production of PE water supply pipes, prestressed corrugated pipes, HDPE corrugated pipes, plastic blind trenches, permeable pipes, etc. The products are mainly used in municipal administration, highways, railways, water conservancy, power, environmental greening and infrastructure construction, and are used in municipalities and expressways. Many national key projects such as railways and railways have been well received by engineering experts and users.
FAQ
Q: Where is your company?
A: We are located in Jiangsu, China.
Q: What is your warranty policy?
A: The product is guaranteed for two years from the date of shipment (or leaving the seller's factory depending on the terms).
It is also guaranteed that the product can be used for 50 years.
Q: How to buy products?
A: Send an email to us and we will get back to you within one day.
