5 Inch 8 Inch Plastic Pvc Water Pipe Prices List For Water Supply Or Drainage
10 Meter/Meters
MOQ
0.5$/m(1~10m);0.43$/m(>1000m)
Price
5 Inch 8 Inch Plastic Pvc Water Pipe Prices List For Water Supply Or Drainage
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: China
Brand Name: HWHP
Certification: ISO9001
Model Number: HM05021
High Light:

anti alkali pvc drainage pipes

,

8 inch pvc drainage pipes

,

lightweight 5 inch plastic drain pipe

Payment & Shipping Terms
Packaging Details: 6m or 12m per piece
Supply Ability: 5000 Metric Ton/Metric Tons per Year
Specifications
Brand Name: HAIYANG
Model Number: HM05021
Specification: DN20mm-630mm
Color: Grey,white,black Or Request
Usage: Water Supply
Raw Material: PVC
Size: Customized Size
MOQ: 100 Meters
Sample: Provide Sample
Advantage: High Quality
Length: As Costomer Requirements
Product Description

5 Inch 8 Inch Plastic Pvc Water Pipe Prices List For Water Supply Or Drainage

----------------------------------------



Basic Info.



Formula design method of plastic pipe
1. PVC plastic pipe technology and design principles
(1) The resin should be PVC-SC5 resin or PVC-SG4 resin, that is, polyvinyl chloride resin with a degree of polymerization of 1200 to 1000.
(2) A thermally stable system must be added. Choose according to the actual requirements of the production, pay attention to the synergistic effect and the antagonistic effect between the heat stabilizers.
(3) Impact modifier must be added. Can choose CPE and ACR impact modifiers. According to the other components in the formula and the plasticizing capacity of the extruder, the addition amount is 8-12 parts. CPE has a low price and a wide range of sources. ACR has high aging resistance and weld fillet strength.

5 Inch 8 Inch Plastic Pvc Water Pipe Prices List For Water Supply Or Drainage 0

DN.mm Wall thickness(mm)
0.63 M pa 0.8Mpa 1.0Mpa 1.25Mpa 1.6Mpa 2.0Mpa
20 - - - - 2.0 2.0
25 - - - - 2.0 2.0
32 - - - - 2.0 2.0
40 - - - - 2.0 2.0
50 - - - - 2.0 2.4
50 - - - 2.0 2.4 3.0
63 - - 2.0 2.5 3.0 3.8
75 - 2.0 2.3 2.9 3.6 4.5
90 2.0 2.2 2.8 3.5 4.3 6.5
110 2.2 2.7 3.4 4.2 5.3 6.6
125 2.5 3.1 3.9 4.8 6.0 7.4
140 2.8 3.5 4.3 5.4 6.7 8.3
160 3.2 4.0 4.9 6.2 7.7 9.5
180 3.6 4.4 5.5 6.9 8.6 10.7
200 3.9 4.9 6.2 7.7 9.6 11.9
225 4.4 5.5 6.9 8.6 10.8 13.4
250 4.9 6.2 7.7 9.6 11.9 14.8
280 5.5 6.9 8.6 10.7 13.4 16.6
315 6.2 7.7 9.7 12.1 15.0 18.7
355 7.0 8.7 10.9 13.6 16.9 21.1
400 7.9 9.8 12.3 15.3 19.1 23.7
450 8.8 11.0 13.8 17.2 21.5 26.7
500 8.9 12.3 15.3 19.1 23.9 29.7
560 11.0 13.7 17.2 21.4 26.7 33.2
630 12.3 15.4 19.3 24.1 30.0 37.4



Advantage



1. It has good tensile and compressive strength.
2. The wall of the pipe is very smooth, so the resistance of the water flow is very small. Its water delivery capacity is 20% higher than that of the cast iron pipe of the same diameter, and the water delivery effect is very high.
3. Corrosion resistance and chemical resistance are also very good, with good acid resistance, alkali resistance, corrosion resistance, not affected by wet moisture and soil pH, and have a long service life.
4. It has good water tightness. Whether this kind of pipe is connected by bonding or rubber ring, it can maintain good water tightness.
5. It has good stretchability and thermal stability, can adapt to different environments and has a wide range of use.
6. With good hardness, it can be used as a drainage pipe, which can prevent the erosion of insects and ants, and has a longer service life.



Details

5 Inch 8 Inch Plastic Pvc Water Pipe Prices List For Water Supply Or Drainage 15 Inch 8 Inch Plastic Pvc Water Pipe Prices List For Water Supply Or Drainage 25 Inch 8 Inch Plastic Pvc Water Pipe Prices List For Water Supply Or Drainage 35 Inch 8 Inch Plastic Pvc Water Pipe Prices List For Water Supply Or Drainage 4








Application



1. Indoor water supply and reclaimed water systems for civil and industrial buildings;
2. Buried water supply system for residential quarters and factories;
3. Urban water supply pipeline system;
4. Water treatment pipeline system of water treatment plant;
5. Marine aquaculture;
6. Garden irrigation, well sinking and other engineering and other industrial pipes.



Certificate



5 Inch 8 Inch Plastic Pvc Water Pipe Prices List For Water Supply Or Drainage 5

5 Inch 8 Inch Plastic Pvc Water Pipe Prices List For Water Supply Or Drainage 6

5 Inch 8 Inch Plastic Pvc Water Pipe Prices List For Water Supply Or Drainage 7

Company Profile



High Mountain Pipe is mainly engaged in PE water supply pipes, hdpe steel wire mesh skeleton composite pipes, PE threading pipes, HDPE double-wall corrugated pipes, PVC drainage pipes, PVC water supply pipes, CPVC power pipes, MPP power pipes, etc. The product model is complete, the quality is reliable, and the company has complete qualifications. , Integrity management, welcome customers to inquire and cooperate.



The company adheres to the people-oriented scientific development concept, correctly grasps product development trends, implements strategic target management, is committed to developing core manufacturing advantages, optimizing resource allocation and technological breakthroughs, introducing market-oriented and refined operating systems, achieving leapfrog development, and striving to build " "Rongchengxing" brand, implement a win-win strategy, and work hard for the development of the industry!





5 Inch 8 Inch Plastic Pvc Water Pipe Prices List For Water Supply Or Drainage 8       5 Inch 8 Inch Plastic Pvc Water Pipe Prices List For Water Supply Or Drainage 9



5 Inch 8 Inch Plastic Pvc Water Pipe Prices List For Water Supply Or Drainage 10       5 Inch 8 Inch Plastic Pvc Water Pipe Prices List For Water Supply Or Drainage 11





FAQ



Q: Can you make special designs and logos on your products?
A: Yes, it is very easy.



Q: Can I customize the size I need?
A: Yes



Q: After reading your FAQ, I am very satisfied. How can I start buying my order?
A: Please contact our sales manager by email or phone, thank you.
