China Suppliers Plumbing 8 Inch PVC U Pipes Thin Wall Large Diameter For Water Supply
10 Meter/Meters
MOQ
0.5$/m(1~10m);0.43$/m(>1000m)
Price
China Suppliers Plumbing 8 Inch PVC U Pipes Thin Wall Large Diameter For Water Supply
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: China
Brand Name: HWHP
Certification: ISO9001
Model Number: HM05024
High Light:

Thin Wall Upvc Pipe

,

Plumbing 8 Inch PVC U Pipes

,

Large Diameter UPVC Pipes

Payment & Shipping Terms
Packaging Details: 6m or 12m per piece
Supply Ability: 5000 Metric Ton/Metric Tons per Year
Specifications
Brand Name: BAITONG
Model Number: HM05024
Specification: DN20mm-630mm
Color: Grey,white,black Or Request
Usage: Water Supply
Raw Material: PVC
Size: Customized Size
MOQ: 100 Meters
Sample: Provide Sample
Advantage: High Quality
Length: As Costomer Requirements
Product Description

China Suppliers Plumbing 8 Inch Thin Wall Pvc Large Diameter Upvc Pipe With Fair Price

----------------------------------------



Basic Info.



UPVC must be modified and granulated before it can be used. PVC is brittle, has poor thermal stability and is not easy to process. It cannot be used directly. It must be modified and compounded, and related additives must be added. The most common modification is modified granulation. Strictly speaking, the PVC modified formula of PVC products with special requirements is tailor-made according to customer requirements.



Outer diameter (mm) Inner diameter (mm) Wall thickness (mm) Pressure
20 16 2 1.0Mpa
25 21 2 1.0Mpa
32 27.2 2.4 1.0Mpa
40 36 2 1.0Mpa
50 45.2 2.4 1.0Mpa
63 57 3 1.0Mpa
75 67.8 3.6 1.0Mpa
90 81.4 4.3 1.0Mpa
110 99.4 5.3 1.0Mpa
140 126.6 6.7 1.0Mpa
160 144.6 7.7 1.0Mpa
225 203.4 10.8 1.0Mpa
280 253.2 13.4 1.0Mpa
315 285 15 1.0Mpa
20 15.4 2.3 1.6Mpa
25 19.4 2.8 1.6Mpa
32 24.8 3.6 1.6Mpa
40 34 3 1.6Mpa
50 42.6 3.7 1.6Mpa
63 53.6 4.7 1.6Mpa
75 63.8 5.6 1.6Mpa
90 76.6 6.7 1.6Mpa
110 93.8 8.1 1.6Mpa
140 119.4 10.3 1.6Mpa
160 136.4 11.8 1.6Mpa
225 191.8 16.6 1.6Mpa
280 238.8 20.6 1.6Mpa
315 268.6 23.2 1.6Mpa


China Suppliers Plumbing 8 Inch PVC U Pipes Thin Wall Large Diameter For Water Supply 0



Advantage



UPVC pipes are also lightweight. The advantage of convenient transportation. The specific gravity of UPVC pipe is about 1.4 (the specific gravity of cast iron pipe is about 7.4), which is one-fifth of the weight of cast iron pipe. Using UPVC pipe can save 1/10-1/5 of the transportation cost compared with cast iron pipe. Its handling, loading and unloading construction are very convenient. The construction environment of water supply pipelines is often difficult, and the construction site is muddy. If it can reduce the labor intensity of workers and shorten the construction period, it is the most ideal thing. The use of UPVC pipe can achieve this ideal. UPVC pipe is light in weight and can be moved manually during the installation process, generally without the use of machinery. For example, a DN200 UPVC pipe with a length of 6m weighs about 55Kg, while a cast iron pipe with the same diameter and length has a dead weight of 304Kg. The UPVC pipe can be carried by one person during installation, while the cast iron pipe requires three people or machinery to drop the pipe, which greatly reduces the It reduces the labor intensity of workers and saves man-hours and construction costs.



Details



China Suppliers Plumbing 8 Inch PVC U Pipes Thin Wall Large Diameter For Water Supply 1     China Suppliers Plumbing 8 Inch PVC U Pipes Thin Wall Large Diameter For Water Supply 2


Application



Construction plumbing works.
UPVC plastic pipe has excellent insulating ability and is also widely used as conduit for post and telecommunication cables.
UPVC plastic pipes are acid and alkali resistant and corrosion resistant, and are used as infusion piping in many chemical plants. Others are also used in well sinking engineering, pharmaceutical piping engineering, mineral brine transportation piping engineering, electrical piping engineering, etc.



Certificate



China Suppliers Plumbing 8 Inch PVC U Pipes Thin Wall Large Diameter For Water Supply 3

China Suppliers Plumbing 8 Inch PVC U Pipes Thin Wall Large Diameter For Water Supply 4

China Suppliers Plumbing 8 Inch PVC U Pipes Thin Wall Large Diameter For Water Supply 5

Company Profile



High Mountain Pipe is a modern emerging enterprise integrating scientific research, development, production and sales. It also sells plumbing equipment from other well-known domestic manufacturers, and its business scope covers various overseas countries and cities.

The company will adhere to the corporate tenet of "survive by quality, develop by service", "abide by contract and respect reputation", and take "integrity, pragmatism, pioneering and enterprising" as its business philosophy to provide you with excellent products and services. Hope to establish long-term friendly cooperative relations with customers from all over the world. Go hand in hand, mutual benefit and create brilliance together.

The company adheres to the belief of "integrity first, mutual benefit, and efficient development", based on the present and focusing on the future. Warmly welcome new and old customers, guests and friends from all walks of life to patronize, consult and guide, work together to create brilliant.



China Suppliers Plumbing 8 Inch PVC U Pipes Thin Wall Large Diameter For Water Supply 6     China Suppliers Plumbing 8 Inch PVC U Pipes Thin Wall Large Diameter For Water Supply 7



China Suppliers Plumbing 8 Inch PVC U Pipes Thin Wall Large Diameter For Water Supply 8       China Suppliers Plumbing 8 Inch PVC U Pipes Thin Wall Large Diameter For Water Supply 9





FAQ



Q: What are your payment terms?
A: Accept the T/T and L/C terms.



Q: After reading your FAQ, I am very satisfied. How can I start buying my order?
A: Please contact our sales manager by email or phone, thank you.
