China Manufactory Cladding Upvc Pipe For Greenhouse Large Diameters For Water Supply
10 Meter/Meters
MOQ
0.5$/m(1~10m);0.43$/m(>1000m)
Price
China Manufactory Cladding Upvc Pipe For Greenhouse Large Diameters For Water Supply
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: China
Brand Name: HWHP
Certification: ISO9001
Model Number: HM05039
High Light:

Cladding Upvc Pipe

,

Upvc Pipe For Water Supply

,

Greenhouse Upvc Pipe

Payment & Shipping Terms
Packaging Details: 6m or 12m per piece
Supply Ability: 5000 Metric Ton/Metric Tons per Year
Specifications
Brand Name: BAITONG
Model Number: HM05039
Specification: DN20mm-630mm
Color: Grey,white,black Or Request
Usage: Water Supply
Raw Material: PVC
Size: Customized Size
MOQ: 100 Meters
Sample: Provide Sample
Advantage: High Quality
Length: As Costomer Requirements
Product Description

China Manufactory Cladding Pvc For Greenhouse Large Diameters Upvc Pipe for water supply

----------------------------------------



Basic Info.



Rigid polyvinyl chloride (PVC-U) pipe is the material for the production of pipes, which should be PVC-U mixed ingredients. The compounding ingredients should be based on PVC resin, in which additives necessary for the production of pipes that meet the requirements of this part should be added, and all additives should be dispersed evenly.



Outer Diameter
DN (mm)
PN25 PN20 PN16 PN12.5 PN10 PN8 PN6.3
Wall Thick Ness(mm) Wall Thick Ness(mm) Wall Thick Ness(mm) Wall Thick Ness(mm) Wall Thick Ness(mm) Wall Thick Ness(mm) Wall Thick Ness(mm)
20 2.3 2.0
25 2.8 2.3 2.0
32 3.6 2.9 2.4 2.0
40 4.5 3.7 3.0 2.4 2.0
50 5.6 4.6 3.7 3.0 2.4 2.0
63 7.1 5.8 4.7 3.8 3.0 2.5 2.0
75 8.4 6.9 5.6 4.5 3.6 2.9 2.3
90 10.1 8.2 6.7 5.4 4.3 3.5 2.8
110 10.0 8.1 6.6 5.3 4.2 3.4 2.7
125 11.4 9.2 7.4 6.0 4.8 3.9 3.1
140 12.7 10.3 8.3 6.7 5.4 4.3 3.5
160 14.6 11.8 9.5 7.7 6.2 4.9 4.0
180 16.4 13.3 10.7 8.6 6.9 5.5 4.4
200 18.2 14.7 11.9 9.6 7.7 6.2 4.9
225   16.6 13.4 10.8 8.6 6.9 5.5
250   18.4 14.8 11.9 9.6 7.7 6.2
280   20.6 16.6 13.4 10.7 8.6 6.9
315   23.2 18.7 15.0 12.1 9.7 7.7
355   26.1 21.1 16.9 13.6 10.9 8.7
400   29.4 23.7 19.1 15.3 12.3 9.8
450   33.1 26.7 21.5 17.2 13.8 11.0
500   36.8 29.7 23.9 19.1 15.3 12.3
560       26.7 21.4 17.2 13.7
630       30.0 24.1 19.3

15.4



China Manufactory Cladding Upvc Pipe For Greenhouse Large Diameters For Water Supply 0



Advantage



1) It has high hardness, stiffness and allowable stress.
2) Good anti-aging ability, durable, lifespan can reach 50 years.
3) Corrosion-resistant, cheap, easy to bond, self-extinguishing.
4) Recyclable. The installation is convenient and simple, and the sealing performance is good.
5) No impact resistance, poor durability, high requirements for joint bonding technology, and long curing time.



Details





China Manufactory Cladding Upvc Pipe For Greenhouse Large Diameters For Water Supply 1     China Manufactory Cladding Upvc Pipe For Greenhouse Large Diameters For Water Supply 2


Application



1) Common specifications classified by pipe diameter: dn20, 25, 32, 40, 50, 63, 75, 90, 110, 125, 140, 160, 180, 200, 225, 250, 280, 315, 355.
Standard length: 6000mmdn≤110; dn≥125 4000, 6000 (mm)
2) According to the interface form, it is divided into two categories: bonding interface and rubber ring interface.
a. Adhesive interface type is used for rigid PVC pipes below dn110, generally used for indoor water supply pipes
Road installation. The overall flexibility of the interface is poor.
b. The rubber ring interface type is used for rigid PVC pipes larger than dn63, and can be used for indoor and outdoor supply
Water pipe installation. The overall flexibility of the interface is good.



Certificate



China Manufactory Cladding Upvc Pipe For Greenhouse Large Diameters For Water Supply 3

China Manufactory Cladding Upvc Pipe For Greenhouse Large Diameters For Water Supply 4

China Manufactory Cladding Upvc Pipe For Greenhouse Large Diameters For Water Supply 5

Company Profile



High Mountain Pipe is a modern emerging enterprise integrating scientific research, development, production and sales. It also sells plumbing equipment from other well-known domestic manufacturers, and its business scope covers various overseas countries and cities.

The company will adhere to the corporate tenet of "survive by quality, develop by service", "abide by contract and respect reputation", and take "integrity, pragmatism, pioneering and enterprising" as its business philosophy to provide you with excellent products and services. Hope to establish long-term friendly cooperative relations with customers from all over the world. Go hand in hand, mutual benefit and create brilliance together.

The company adheres to the belief of "integrity first, mutual benefit, and efficient development", based on the present and focusing on the future. Warmly welcome new and old customers, guests and friends from all walks of life to patronize, consult and guide, work together to create brilliant.



China Manufactory Cladding Upvc Pipe For Greenhouse Large Diameters For Water Supply 6     China Manufactory Cladding Upvc Pipe For Greenhouse Large Diameters For Water Supply 7



China Manufactory Cladding Upvc Pipe For Greenhouse Large Diameters For Water Supply 8       China Manufactory Cladding Upvc Pipe For Greenhouse Large Diameters For Water Supply 9





FAQ



Q: Is the price on this page correct?
A: The listed prices are for reference only, please contact us directly for the latest prices.



Q: What is the purpose of this pipeline?
A: It is mainly used to transport liquids, and is used on a large scale in urban water supply projects, farmland irrigation, etc.



Q: What certificates do you have for this product?
A: ISO, CE, SGS, etc.
